| Brand | X-Security |
| Range | ULTRA |
| Image sensor | 1/2.8“ Progressive Scan CMOS |
| Resolution | PTZ: 4 Megapixel (2560×1440)Panoramic: 4 Megapixel (2560×1440) |
| Main Stream rate | PTZ:2560x1440 @25fps;2048x1536 @25fps;2304x1296 @25fps;1920x1080 @25fps;1280x960 @25fps;1280x720 @25fpsPanoramic:3840x1080 @25fps |
| Extra Stream Rate 1 | PTZ:704x576 @25fps;640x480 @25fps;352x288 @25fpsPanoramic:960x268 @25fps;704x576 @25fps;640x480 @25fps;352x288 @25fps |
| Extra Stream Rate 2 | PTZ:1280x720 @25fpsPanoramic:1920x540 @25fps;1920x1080 @25fps;1280x960 @25fps;1280x720 @25fps |
| Minimum illumination | PTZ: 0.005 Lux Color@(F1.6, AGC ON) / 0 lux with IRIR range: 200 mPanoramic: 0.001 Lux Color@(F1.0, AGC ON) / B/W: 0.0001 Lux Color@(F1.0, AGC ON)Scope White light: 30 mStarlight, color image in low l |
| Compression | Smart H.265+/ Smart H.264+/ H.265/ H.264H/ H.264B/ H.264M /MJPEG (extra stream) |
| Bitrate | PTZ:H.264: 2.816 kbps-13.056 kbpsH.265: 1.024 kbps-7.936 kbpsPanoramic:H.264: 2.816 kbps-13.824 kbpsH.265: 1.024 kbps-8.192 kbps |
| Lens | PTZ: Varifocal 5~125 mm (Optical Zoom 25X)Panoramic: 2.8 mm |
| Viewing Angle (FOV) | PTZ: H: 53.4~3.4o, V: 30.4o~1.95o, D: 59.3o~3.9oOverview: H: 180o ±5o, V: 51o |
| Range performance | PTZ:2500 m (D), 987.5 (O), 500 (R), 250 (I)Overview:38.6 m (D), 15.3 (O), 7.7 (R), 3.9 (I) |
| Digital zoom | 16x |
| Electronic Shutter | PTZ: 1~1/30.000 sPanoramic: 1~1/10.000 s |
| Day / Night | Removable mechanical ICR filter |
| Auto Focus | PTZ: Semi-auto, Manual or Auto |
| Image improvements | WDR (120 dB), BLC, HLC, 2D/3D-DNR, AGC, AWB, Privacy Masking, ROI, Flip |
| EIS (Image Stabilizer) | Yes |
| Motion Detection | Yes |
| IVS (Perimeter protection) | Intrusion, tripwire (both functions support the accurate classification and detection of vehicles and persons) |
| Face detection | Supports face detection, optimization, tracking, image capture, uploading of high quality face shots. Extracts 6 attributes and 8 expressions. Allows you to cut out faces: Face, one inch photo. Captur |
| Pan/Tilt Range | Horizontal: 360°, Vertical: -20°~90° |
| Manual speed | Horizontal: 0.1~ 160°/s, Vertical: 0.1~120°/s |
| Speed between Presets | Horizontal: 240°/s, Vertical: 200°/s |
| Preset positions | 300 preset, 5 auto pattern, 8 auto tour, auto pan, auto scan |
| Autotracking | YES |
| Internal memory | MicroSD card slot up to 512 GB |
| Alarms | 2 IN / 1 OUT |
| Active Deterrence | Siren and strobe flash integrated in the cameraWhite lightFlash duration: 5~30 sIt has 11 alarm sounds |
| Audio | 1 Input / 1 Output |
| Audio Compression | PCM; G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1; G729; G723 |
| PTZ Control | Through network access |
| Network interface | Ethernet 10 / 100 BaseT |
| Remote access | WEB, CMS (DMSS/DSS Pro), Smartphone and NVR interface |
| Interoperability | ONVIF (S-profile, G-profile, T-profile), CGI |
| Power | DC 36 V, max. 32 W |
| Temp. operation | -40o C ~ +65o C |
| Degree of protection | Weatherproof IP66 |
| Material | Aluminium alloy and plastic |
| Dimensions (without bracket) | 359.8 mm (H) x 247 mm (D) x 202 mm (W) |
| Weight (without bracket) | 5.3 kg |
