| Brand | X-Security |
| Inputs for IP cameras | LAN port up to 16 channels |
| Bandwidth | AI deactivated: 384 Incoming Mbps, 384 Recording Mbps and 384 Outgoing Mbps AI enabled: 200 Incoming Mbps, 200 Recording Mbps and 200 Outgoing Mbps |
| N+M Cluster | Supported |
| Video outputs | 2 HDMI 4K & 2 VGA |
| Bidirectional audio | 1 input, 2 output, RCA |
| Video compression format | Smart H.265+; H.265; Smart H.264+; H.264; MJPEG |
| Display resolution | 32 MP; 24 MP; 16 MP; 12 MP; 8 MP; 5 MP; 4 MP; 1080p; 720p; D1; CIF; QCIF |
| Decoding capacity | AI disabled: 2 channels 32 MP@20 fps; 2 channels 24 MP@20 fps; 4 channels 16 MP@30 fps; 5 channels 12 MP@30 8 fps; 8 channels MP@30 12 fps; 5 channels MP@30 16 fps; 4 channels MP@30 32 fps; 1080p@30 c |
| AI through recorder | Face detection; face recognition; perimeter protection; SMD Plus |
| AI per camera | Face detection; facial recognition; video metadata (human, motorized and non-motorized vehicles); perimeter protection; SMD Plus; stereo analysis; crowd distribution; people counting; ANPR; vehicle de |
| AcuPick AI for camera + recorder | Max. 16 channels, 1 combined event per channel(s) |
| AI perimeter performance per recorder (number of channels) | 4 channels, 10 IVS rules for each channel |
| AI perimetric performance per camera (number of channels) | 16 channels |
| Face detection | Gender; Age group; Glasses; Expressions; Mask; Beard; |
| Network port | 1 (Ethernet port 10/100/1000 Mbps, RJ-45)) |
| AI face detection performance per recorder (number of channels) | 2 channels (up to 12 facial images per channel) |
| AI face detection performance per camera (number of channels) | 16 channels |
| Database capacity Face | Up to 20 face databases with 20,000 images can be added, with a total capacity of 2.5 G. Name, gender, date of birth, address, credential type, credential number, countries and regions, and state can |
| AI face recognition performance per recorder (number of channels) | 1. FD of 8 channels (per camera) + FR (per recorder), image stream: 16 facial images / s2. 2-channe FD (per recorder) + FR (per recorder), video stream: 12 facial images / s |
| AI face recognition performance per camera (number of channels) | 16 channels |
| SMD Plus | SMD Plus per recorder; 8 channels: Secondary filtering for human and motorized vehicles, reducing false alarms caused by leaves, rain and changing lighting conditionsSMD Plus per camera; 16 channels |
| AI metadata throughput per camera (number of channels) | 8 channels |
| Human attributes | Top color, top type, bottom color, bottom type, hat, bag, age, gender and umbrella |
| Recording method | Manual, programmed, motion detection, alarm |
| Intelligent functions | Line Crossing, Intrusion, Abandoned Object, Face Detection, Heat Map |
| Backup | USB (Memory, HDD, CD-RW, DVR-RW) / Network / SATA |
| Motor vehicle attributes | License plate, license plate color, vehicle body, vehicle model, vehicle logo, call sign, seat belt, vehicle interior, vehicle registration location. |
| Attributes of non-motorized vehicles | Model of vehicle, color of vehicle, number of persons, helmet, etc. |
| ANPR per camera (number of channels) | 8 channels |
| License plate database capacity | 1. Creates up to 20.000 plate numbers.2. Block list and allow list |
| Alarms | 16 Inputs / 6 Relay NO/NC |
| Internal memory | 4 SATA HDD 3.5" of up to 16 TB (not included) |
| Communications ports | RS-232, RS-485 and eSATA |
| Access to third party cameras | ONVIF 22.06 (T-Profile; S-Profile; G-Profile); .CGI; SDK |
| Communication | 3xUSB Ports / 1 RJ45 10/100/1000M (Ethernet) |
| Remote access | Web browser (ActiveX), mobile phone application or PSS software |
| Power | 100 ~ 240 VAC / 25,5W |
| Dimensions | 70(Al) x 440 (W) x 415.1 (D) mm |
| Weight | 4,82 kg |
