| Brand | X-Security |
| Image sensor | 1/2.8" STARVIS™ CMOS |
| Lens | Varifocal 5 ~ 125 mm (Optical zoom 25X) Auto Iris, Auto Focus |
| Digital zoom | 25 X |
| Resolution | 4K (3840 × 2160); 4M (2560 × 1440); 3M (2048 × 1536); 3M (2304 × 1296); 1080p (1920 × 1080); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA(640×480); CIF (352 × 288/352 × 240) |
| Compression | H.264H; H.264B; Smart H.265+; H.264; H.265; MJPEG (Sub Stream); Smart H.264+ |
| Main Stream rate | 4K / 4M / 1080p / 1.3M / 720p (1-25/30 fps) |
| Extra Stream rate | Sub stream 1: D1/VGA/CIF (1–25/30 fps) Sub stream 2: 1080p/1.3M/720p/CIF (1–25/30 fps) |
| Bitrate | H.264: 3.328 kbps–8.192 kbps H.265: 1.280 kbps–8.192 kbps |
| Image improvements | WDR (120dB),2D/ 3DNR, HLC, BLC, ATW, AGC, Privacy Mask |
| Minimum illumination | Colour: 0.005 lux@F1.6B/W: 0.0005 lux@F1.60 lux@F1.6 (IR light on) |
| SMD | Yes |
| IVS (Perimeter protection) | Tripwire; intrusion; cross-fence detection; loitering detection; abandoned/lost object; fast motion; parking detection; people gathering; vehicle/human alarm classification |
| Face detection | Supports face detection, optimization, tracking, image capture, high quality facial snapshot uploading and facial enhancement; Supports attribute extraction. 6 attributes and 8 expressions: Gender, ag |
| Day / Night | Removable mechanical ICR filter |
| Network interface | Ethernet 10/100 BaseT |
| Remote access | WEB interface, CMS software, mobile application and NVR |
| Memory | Slot for Micro SD card (Max 256 GB) |
| Pan/Tilt Range | Horizontal: 0°~360°, Vertical: -15°~90° auto flip 180° |
| Manual speed | Horizontal: 0.1°~200° /s, Vertical: 0.1°~120° /s |
| Speed between Presets | Horizontal: 240° /s, Vertical: 200° /s |
| Preset positions | 300, 5 auto pattern, 8 auto tour, 5 auto scan |
| Communication | DH-SD, ONVIF Compatible |
| Audio | 1 Input / 1 Output |
| Audio Compression | PCM; G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1; G729; G723 |
| Alarms | 2 inputs / 1 relay NO/NC |
| Power | DC 12 V / 3 A, PoE+(802.3at) |
| Protection | IP66, TVS 6000 V lightning-proof; surge protection; transient voltage protection |
| Temp. operation | -40o C ~ +70o C |
| Dimensions | 270,4 mm (H) x 160 (O) mm |
| Weight | 2,4 Kg |
