V2801RGW V SOL Router ONT Wi Fi 4 1X PON 1x LAN RJ45 10/100/1000Mbps

V-SOL Router ONT Wi-Fi 4
1X PON 1x LAN RJ45 10/100/1000Mbps
802.11ac 2x2 double band 2.4 and 5GHz
Ideal for home and business FTTH

Brand: VSOL

Šifra: V2801RGW

40,75 EUR

Visoka dostupnost

Dostupnost Dostupno

Načini plaćanja: Pouzećem, online plaćanje po broju narudžbe, PayPal

Specifikacije

Brand	V-SOL
Interface	1X PON 1x LAN RJ45 10/100/1000Mbps
PON	XPON Port (EPON PX20+ and GPON Class B+)Single-mode SC, SC/UPC connectorOptical transmission power: 0 to +4 dBmReceiving sensitivity: -27 dBmOptical overload power: -3 dBm (EPON) o -8 dBm (GPON)Transm
WiFi Antennas	Complies with IEEE802.11b/g/n/acWi-Fi: 2,4 GHz, 5 GHz 2x2, speed up to 1,167 Gbps, multiple SSIDsTransmission power: 2,4 GHz: 18 dBm; 5 GHz: 17 dBmReceiving power: 2,4 GHz: HT40-MCS7 -71 dBm; 5 GHz: V
Funciones WiFi	802.11b/g/n/ac integradoAutenticación: WAP-PSK (TKIP)/WAP2-PSK (AES)Múltiples SSIDSSID ocultosWiFi MeshAdmite hasta 64 conexiones de dispositivos
Protocolos de Gestión	OAM/OMCI/Telnet/Web/TR069Admite la gestión completa de las funciones de HGU mediante VSOL OLT
Funciones de capa 2 ( switching )	Compatible con bridge 802.1D y 802.1ad, VLAN 802.1Q
Funciones de capa 3 ( routing )	IPv4, IPv6 e IPv4/IPv6 dual stackDHCP/PPPOE/EstáticoRuta estática, servidor DHCPNAT/DMZ/DDNS/Servidor virtual
Multicast	IGMP v1/v2/v3, espionaje IGMPProxy IGMPEspionaje MLD v1/v2Proxy MLD
QoS	Admite 4 colas de QoS ( Voip, IPTV, Internet ..)Compatible con SP, WRR, 802.1P y DSCP
Seguridad	Funciones básicas de firewall Filtrado de MAC basado en MAC o URLACLsCompatible con detección de bucles
Funciones del sistema	NTP (Protocolo de Tiempo de Red) Reinicio programado del dispositivoHerramientas de diagnósticos de ping y traceroute
Color	Blanco
Dimensiones	170mm x 112mm x 31mm
Peso	170g
Temp. Funcionamiento	0o C ~ +55o C
Alimentación	DC 12V 1A (adaptador incluido)

Opis

The V2801RGW (XPON 1GE + WiFi 4 ONT) is a broadband access device specially designed to meet the needs of telecom operators in FTTO (office), FTTD (desktop), FTTH (home), SOHO access and video surveillance.

The ONT is based on high-performance chips, supports dual-mode XPON technology (EPON and GPON), as well as IEEE802.11b/g/n WiFi 4 technology and other layered 2/capa 3, functions providing data services for carrier-grade FTTH applications. In addition, the ONT also supports the OAM/OMCI protocol, which allows configuring or managing various ONT services on the VSOL OLT.

The ONT offers high reliability, is easy to manage and maintain, and has quality of service (QoS) guarantees for various services. Complies with a number of international technical standards such as IEEE802.3ah and ITU-T G.984.
