| Brand | ThermTec |
| Thermal sensor | 640x512 Vanadium oxide |
| Thermal focus | Motorized |
| Optical sensor | 1/2.8” Progressive Scan CMOS 4 Megapixel |
| Main Stream rate | Term: 1280x720 / 768x576 / 640x480 / 384x288 (25fps)Opt: 2592x1536 / 1920x1080 / 1280x720 ?(25fps) |
| Extra Stream rate | Term: 768x576 / 640x480 / 352x288 / 384x288 (25fps)Opt: 1280x720 / 768x576 / 640x480 / 384x288 (25fps) |
| Image Fusion | Supported |
| Compression | H.265 / H.264 |
| Image enhancement | DWDR, 3DNR, BLC, HLC AGC, ROI, Privacy Mask |
| Lens | 10mm (Term) / 8mm (Opt) |
| Thermal viewing angle | 43,3°×34,6° (Therm) |
| Thermal sensitivity | ?35mK (0.05 o C) |
| Thermal measurement range | -20~150oC / ±8oC |
| Spectral range | 8~14µm |
| Pitch detector | 12µm |
| Audio | Does not have |
| Alarms | 1 IN / 1 OUT |
| Internal memory | EMMC up to 16GB |
| Network interface | Ethernet 10/100M BaseT |
| Remote access | WEB Interface |
| Interoperability | ONVIF Profile S/T |
| Power | 12VDC, max.15W / PoE (802.3af) |
| Temp. operation | -20oC~+60oC |
| Degree of protection | Waterproof IP66, TVS |
| Dimensions | 356 x 145 x 162 mm |
| Weight | ?2200 g. |
