| Brand | Safire Smart |
| Range | B2 NVR series |
| Inputs for IP cameras | 16CH IP |
| Power over Ethernet | 16 RJ45 10/100MPower ?150W, PoE IEEE802.3af/at |
| IP compatible cameras | Safire Smart (native protocol), ONVIF |
| Bidirectional audio | 1 input / 1 RCA output |
| Main stream recording | 8MP/6MP/5MP/3MP/1080P /UXGA /720P /VGA /4CIF /DCIF /2CIF /CIF /QCIF |
| Decoding capacity | 1CH 8Mpx @ 20FPS6CH 1080P @ 30FPS |
| Video compression format | H.265S / H.265+ / H.265 / H.264+ / H.264 |
| Audio Compression | G.711(U/A) |
| Total bandwidth | 160Mbps input / 160Mbps output |
| Video outputs | 1 HDMI 4K, 1 VGA |
| Display resolution | HDMI 1: 3840x2160@30FPS, 1920x1080, 1280x1024, 1024x768VGA: 1920x1080, 1280x1024, 1024x768 |
| Yesmultaneous multifunction | Pentaplex: Live, Recording, Playback, Backup and Remote Access |
| Multi-Screen | 1 / 4 / 6 / 8 / 9 / 13 / /16 [%VAR%] (Live view) |
| Recording method | Manual, programmed, motion detection, intelligent events, alarm |
| POS Function | Si |
| Perimeter Protection | Up to 2CH by the recorder itselfOn all channels using Safire Smart cameras 4I1 or 8I2.Artificial Intelligence based on the classification of humans, vehicles and two-wheeled vehicles on:- Area intrusi |
| Facial Detection | Up to 2CH by the recorder itselfFace detection with Safire Smart cameras 4I1 or 8I2 up to 16CH (All channels)Face detection statistics chart by day, week, month, year. |
| Video metadata | Up to 2CH by the recorder itselfFor classification and attribute extraction it is necessary to use Safire Smart 4I1 or 8I2, cameras in order to obtain:For humans: Can extract up to 13 features (glasse |
| License plate recognition | Yes (Safire Smart license plate camera required) |
| Dewarping | Supports Fisheye camera dewarping |
| Alarms | Does not have |
| External Backup | USB / HDD USB memory |
| Internal memory | 2 3.5" HDD SATA3.0 up to 10 TB (not included) |
| Communication | 2 x USB 2.0 / 1 x RJ45 (Ethernet) |
| Remote access | Safire Smart Control Center Web Browser, Smartphone App and PC Software |
| Power | DC48V, 3.75A ? 10W (No hard disk) |
| Operating temperature | -10oC ~50oC, Humidity 10~90% |
| Dimensions / weight | 45 (H) x 380 (W) x 268 (D) mm / 3.0 Kg |
