| Allowed wavelength | 1260 nm to 1650nm |
| Fiber type | PON |
| Connector type | SC |
| Basic specifications | Plug and PlayMultiple installation methodsHigh Splitting reliabilityCompact size |
| PON Specifications | Loss regarding temperature (dB) ? 0,3Loss regarding wavelength (dB) 0.4 (1310 + 40), 0.4 (1550 + 40)Insertion loss (dB) ? 17,7Port insertion uniformity losses (dB) ? 1.5Return loss (dB) ? 50Loss regar |
| Material | Metallic |
| Electric Consumption | No power consumption (it is a passive element) |
| Operating temperature | -40° C ~ 85° C |
| Dimensions | 42 (H) x 220 (W) ×130 (D)mm |
| Weight | 0,98 kg |
