| Brand | Reyee |
| Wireless Standard | Proprietary Protocol |
| Mode of operation | Point to Point / Point - Multipoint (up to 16 CPE) |
| Frequencies | 5.15GHz - 5.85 GHz and 2.412 GHz - 2.472 GHz (Management network) |
| 5 GHz Channel Width | Auto/20/40/80 MHz |
| 2,4 GHz Channel Width | Auto/20/40 MHz |
| Distance | Up to 5 km in ideal conditions |
| TDMA | Fixed Mode / Flexible Mode |
| Maximum transmitting power 2,4 Ghz | 100 mW (20 dBm) |
| Maximum transmitting power 5 Ghz | 400 mW (26 dBm) |
| Integrated antenna | 15 dBi Dual directional |
| Ports | 3 x 10/100/1000Base-T RJ45 |
| Management | Configuration via web interface, One-click configuration, AI Heatmap for Bridge, Bridge Alignment Tool, Spectrum Scan and Link Optimization, configuration with management radius at 2,4 Ghz |
| Additional functionalities | Management security WPA2-PSK, Internet access from the management radio, SSID Masquerading, Spectrum Analysis, Alignment Tools, One-Touch Pairing, WMM, Storm Control, VLAN Packet Transmit, DHCP Server |
| Power | 12 VDC and 24 VDC non-standard POEPoE 802.3af/at |
| Overvoltage protection | Common: ±4 kV Differential: ±2 kV |
| Electrostatic Discharge Protection | Contacto=8 kV, Discharge Aérea=15 kV |
| Power consumption | < 12 W |
| Operating temperature | -40 °C ~ 80 °C (When using power adapter the maximum operating temperature of the device and power adapter is 60o max) |
| Dimensions | 355 ×124 ×48 mm (Without anchor) |
| Weight | 830 g |
The RG-EST450G is a high-performance wireless station, designed for PTMP (point-to-multipoint) applications in the 5 GHz band, with a wide horizontal coverage of 120°. Ideal for video surveillance deployments, connections between multiple locations and demanding outdoor environments requiring high capacity and stability.
Among its main features are:
Wireless speeds up to 867 Mbps at 5 GHz and 150 Mbps at 2.4 GHz, with support for Wi-Fi 5 (802.11ac) and technologies such as 2x2 MIMO and 256-QAM modulation for higher throughput.
Coverage up to 5 km. It is capable of supporting up to 16 PTMP links, ideal for connecting multiple devices or IP cameras from a single central point.
Horizontal coverage angle of 120° and antenna gain of 15 dBi, ensuring wide and efficient coverage for remote stations.
Advanced alignment and management tools, such as spectrum scanning, network diagnostics, speed testing, and coverage visualization with AI Heatmap.
Compatibility with Ruijie's SON (Self-Organizing Network) function, which allows the device to be easily integrated with other Reyee series equipment for simplified management.
Flexible power supply via PoE 802.3af/at, Passive PoE or direct DC source, adaptable to different installation environments.
Rugged design with IP55 certification and ESD protection up to 15 kV, ideal for operation in harsh outdoor conditions.
Unlike the RG-EST350G, model, the RG-EST450G is supplied as a single unit, intended to act as a base station in multipoint topologies, so it can be paired with several compatible CPEs, such as the RG-EST350G.
