| Technology | LoRaWAN® |
| Frequency band | 868 MHz |
| Power Output | 16dBm Max. |
| Sensitivity | -137 dBm @300bps |
| Mode | OTAA/ABP Class C |
| Scope of communication | Up to 15Km range with direct vision |
| Field of view | 190 ° Horizontal, 112 ° Vertical |
| Detection area | Radius of 5m at a height of 3m (78?) |
| Light sensor | Bright/Dark (setting between 1-60000 lux as Bright or Dark according to the customized threshold) |
| Configuration | NFC via smartphone APP |
| Power | 1x Battery 1650 mAh ER14335 Li-SOCI2 |
| Battery Life | 4 years (30 detections/day) |
| Operating temperature | -20oC to 60oC (Relative humidity < 90%)) |
| Protection Grade | IP30 |
| Dimensions | 23.8 (D) x 50 (H) x 50 (W) mm |
| Material | Anti-flame polycarbonate |
| Colour | White |
| Certificates | CE, FCC, RoHS |
| Installation height | 2.5~4m |
| Recognition rate | Counting regions: up to 95%Counting line crossings: up to 98% |
