| Technology | LoRaWAN® |
| Frequency band | 868 MHz |
| Power Output | 16dBm Max. |
| Sensitivity | -137 dBm @300bps |
| Mode | OTAA/ABP Class A |
| Temperature Sensor | Range: -20°C a + 70°CAccuracy: ±0.3°C (0°C – 70°C), ±0.6°C (-40°C – 0°C)Resolution: 0.1oC |
| Humidity sensor | Range: 0% a100% RHAccuracy: ±3% RH (10% – 90%), ±5% RH (0% – 10%, 90% – 100%)Resolution: 0.5% RH |
| CO2 Sensor | Range: 400 - 5000 ppmAccuracy: ± (30 ppm +3 % of reading)Resolution: 1 ppm |
| Screen | 2.13" of e-ink. |
| Battery duration | About 3 year |
| Power supply | 2x 2700 mAh ER14505 Li-SOCl2 |
| Operating temperature | -20°C to +60°C |
| Environmental protection | IP30 |
| Dimensions | 68x65x20.5 mm |
| Hardware | CPU: 528 MHz, ARM Cortex-A7Memory: 256 MB DDR4 RAMFlash: 4 GB eMMC |
| Antennas | 2x External Lora Antenna N-Female ConnectorInternal Wi-Fi Antenna |
| Channels | 8 |
| Connected devices | 2000 end devices |
| Sensitivity | 140dBm@292bps |
| Power Output | 27dBm Max. |
| Protocol | V1.0 A-Class / B-Class / C-Class and V1.0.2 A-Class / B-Class / C-Class |
| Ethernet | 1x RJ45 10/100Mbps Base-T (IEEE 802.3)Full or Half-Duplex mode with auto-detectionAuto MDI/MDIX |
| Network Protocols | PPPoE, SNMP v1/v2c/v3, TCP, UDP, DHCP, DDNS,HTTP, HTTPS, DNS, ARP, SNTP, Telnet, SSH, MQTT, etc. |
| VPN Tunnel | OpenVPN/IPsec/PPTP/L2TP/GRE/DMVPN |
| Access Authentication | CHAP/PAP/MS-CHAP/MS-CHAPV2 |
| Firewall | ACL/DMZ/Port mapping/MAC binding/URL filtering |
| Management | Web, CLI, SMS, On-Demand Phone Access, Hub, Milesight IoT Cloud |
| Milesight IoT Cloud PRO | 1 year included with the kit |
| Reliability | WAN failover |
| Integrated functions | Watchdog, RTC, Timer |
| Power | 5V Type-C port, 802.3af, ? 3.3Max PoE. |
| Operating temperature | -20oC to 70oC (Relative humidity < 95%)) |
| Storing temperature | -40oC to 85oC |
| Ethernet isolation | 1.5kV RMS |
| Protection Grade | IP65 |
| Dimensions | ? 115 x 21 mm |
| Mounting | Desk, Ceiling or Pole |
| Certificates | CE, FCC |
| Battery duration | About 4 years |
| Temperature Sensor | Sensor type: MEMSRange: -20°C a + 60°CAccuracy: ±0.2°CResolution: 0.1oC |
| Humidity sensor | Sensor type: MEMSRange: 0% a100% RHAccuracy: ±2% RHResolution: 0.5% RH |
| Light sensor | Sensor type: PhotodiodeRange: 0-60000 lux |
| CO2 Sensor | Sensor type: NDIRRange: 400 - 5000 ppm NDIRAccuracy: ± (30 ppm +3 % of reading)Resolution: 1 ppm |
| TVOC sensor | Sensor type: MEMSRange: 1.00 - 5.00 (IAQ Rating)Accuracy: ±1Resolution: 0.01 |
| Barometric pressure sensor | Sensor type: MEMSRange: 260 - 1260 hPaAccuracy: ±0.5 hPaResolution: 0.1 hPa |
| PIR sensor | Detection distance: 5mDetection angle: 80° horizontal, 55° verticalState: Free or occupied |
| Screen | 4.2" of e-ink. |
| Power supply | 4x 2700mAh ER14505 or powered via USB type C |
| Operating temperature | -20°C ~ +60°C |
| Dimensions | 100.8×114×22 mm |
| Mode | OTAA/ABP Class C |
| PM2.5&PM10 | Sensor type: Laser detectionRange: 0 ~ 1000 µg/m3Accuracy: 0~100(±10µg/m3), 100~1000(±10 %) (-10°C~ 60°C)Resolution: 1 µg/m3 |
| Formaldehyde (HCHO) | Sensor type: ElectrochemicalRange: 0 ~ 1.25 mg/m3Accuracy: ±10 %Resolution: 0.01 mg/m3Service life: 6 years |
| Ozone (O3) | Sensor type: ElectrochemicalRange: 0 ~ 10 ppm µg/m3Accuracy: ±5 % FSResolution: 0.01 ppmService life: 2 years |
| Power supply | powered via USB Type-C 5V/1A |
