| Brand | X-Security |
| Image sensor | 1/29” Progressive CMOS |
| Maximum resolution | 4 Megapixel (2688x1520) |
| Lens | 2.7 ~ 13.5 mm (H: 104°–29° V: 54°–16° D: 125°–33°) |
| Range performance | 64-210 (D), 25.6-84 (O), 12.8-42 (R), 6.4-21 (I) |
| Main Stream rate | 2688 × 1520 @ (1–25/30) fps |
| Extra Stream rate | Sub stream 1: 704 × 576 @ (1–25 fps)/704 × 480 @ (1–30 fps)Sub stream 2: 1920 × 1080 @ (1–25/30 fps) |
| Compression | H.265; H.264; H.264H; H.264B; MJPEG (only compatible with substream) |
| Intelligent codec | Smart H.265+Smart H.264+ |
| AI Coding | AI H.265AI H.264 |
| Minimum illumination | 0,005 lux@F1,5 (color, 30 IRE) 0,0005 lux@F1,5 (black and white, 30 IRE) 0 lux (illuminator on) |
| IVS (Perimeter protection) | Tripwire, intrusion (support accurate classification and detection of vehicles and people); |
| AI SSA (AI Scene Selfadaptation) | Yes |
| Intelligent search | Work together with Smart NVR to refine intelligent search, event extraction and merging with event videos |
| SMD 4.0 | Yes |
| Image improvements | WDR 120dB, BLC, HLC, AWB, AGC, 3D-NR, ROI , Smart IR |
| Day / Night | Removable mechanical ICR filter |
| Network interface | Ethernet 10/100 BaseT |
| Material | Metallic |
| Remote access | WEB, CMS (DSS/PSS), Smartphone and NVR interface |
| Interoperability | ONVIF (S Profile /G Profile /T Profile ); .CGI; P2P; Milestone; Genetec |
| Power | DC 12 V / 3.6 W, PoE IEEE802.3af |
| Temp. operation | -30o C ~ +60o C |
| Degree of protection | Weatherproof IP67, Anti-vandal IK10 |
| Dimensions | 94 mm (D) x 122 (O) mm |
| Weight | 713 g |
