| Brand | Hikvision |
| Range | PRO |
| Video format | HDTVI / HDCVI / AHD / CVBS / IP |
| Video inputs | 8 Channels BNC (HDTVI / HDCVI / AHD / CVBS) |
| Hybrid configuration | 2CH additional IP: Up to 10 IP channels (6 Mpx), replacing all BNC channelsEnhanced IP Mode:4CH additional IPs: Up to 12 IP (6 Mpx channels), replacing all BNC channels* Enhanced IP mode may conflict |
| Video outputs | 1 HDMI Full HD and 1 VGA, simultaneous; 1 BNC CVBS |
| Display resolution | HDMI: 1920x1080, 1280x1024, 1280x720VGA: 1920x1080, 1280x1024, 1280x720CVBS: 704x576 (PAL) / 704x480 (NTSC) |
| Audio inputs | 8 inputs8 coaxial audio channels |
| Audio outputs | 1 Channel RCA |
| Bidirectional audio | Reusing the audio input |
| Audio bit rate | 64 Kbps |
| Audio Compression | G.711u |
| Video compression | Analog: H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264IP: H.265+ / H.265 / H.264+ / H.264 |
| Recording resolution | With 1080p Lite mode not enabled:3K Lite / 5 Mpx Lite / 4Mpx Lite / 1080p / 720p / WD1 / 4CIF / VGA / CIFWith 1080p Lite mode enabled:3K Lite / 5Mpx Lite / 4Mpx Lite / 1080p Lite / 720p Lite / WD1 / 4 |
| Input resolution | HDTVI: 3K (20 fps), 5Mpx (20 fps), 4Mpx (25~30 fps), 1080p (25~30 fps), 720p (25~30 fps)HDCVI: 5Mpx (20 fps), 4Mpx (25~30 fps),1080p (25~30 fps), 720p (25~30 fps)AHD: 5Mpx (20 fps), 4Mpx (25~30 fps),1 |
| Main Stream coding | 1080P Lite not enabledStream 3K: 3K Lite (12 FPS), 4 Mpx Lite/1080p (15 FPS); 720p/WD1/4CIF/VGA/CIF (20 FPS)Stream of 5 Mpx: 5 Mpx Lite (12 FPS), 4 MP Lite/1080p (15 FPS), 720p/VGA/WD1/4CIF/CIF (20 F |
| Extra Stream coding | WD1 / 4CIF (12FPS) / CIF (25 FPS) |
| Video Bit Rate | 32 Kbps at 6 Mbps |
| Simultaneous multifunction | Pentaplex: Live, Recording, Playback, Backup and Remote Access |
| Alarms | 8 inputs / 4 outputs |
| Motion Detection | Motion detection 2.0: Deep-learning based motion detection, can classify humans and vehicles upon motion detection.Enabled by default on all analog channels.* Motion detection and AcuSense cannot be e |
| Intelligent functions | Acusense: Perimeter protection based on VCA rules with false alarm filter for human and vehicle detection applied on: Line Crossing, Area Intrusion.Available in up to 4 analog video channels.* Motion |
| Face Recognition | Face image comparison, image search with faces up to 2 channels.Up to 16 face libraries. |
| Recording method | Manual, programmed, motion detection |
| Backup | USB (Memory, HDD, CD-RW, DVR-RW) / Network |
| Internal memory | 2 SATA HDD 3.5" of up to 10 TB (not included) |
| Communication | 1xUSB 2.0 (front side), 1xUSB 2.0 (rear side) / 1xRJ45 (Ethernet) / 1xRS-485 half-duplex |
| Bandwidth | 96 Mbps |
| Remote connections | 64 |
| Remote access | Web Browser, Hik-Connect Smartphone App, PC Software iVMS-4200 and Hik-Central |
| Power | DC 12 V, 2.5A, ? 30 W |
| Operating temperature | -10° ~ +55° C |
| Dimensions | 52 (H) mm x 384 (W) mm x 313 (D) mm |
| Weight | ? 1.78 Kg |
