| Brand | Hikvision |
| Range | Value |
| Video format | HDTVI / HDCVI / AHD / CVBS / IP |
| Video inputs | 16 Channels BNC, (HDTVI / HDCVI / AHD / CVBS) |
| Hybrid configuration | 8 Additional IP CH: Up to 24 IP channels (8 Mpx), replacing all BNC channels |
| Video outputs | 1 BNC CVBS (1.0 Vp-p 75 ?)Resolution: PAL: 704 × 576, / NTSC: 704 × 480 |
| Audio inputs | 4 RCA channels |
| Audio outputs | 1 Channel RCA |
| Bidirectional audio | Reusing the audio input (Using the first RCA audio input) |
| Audio bit rate | 64 Kbps |
| Audio Compression | G.711u |
| Video compression | Analog: H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264IP: H.265+ / H.265 / H.264+ / H.264 |
| Input resolution | HDTVI: 8Mpx, 5Mpx, 4Mpx, 3Mpx, 1080p30FPS, 1080p@25FPS, 720p@60FPS, 720p@50FPS, 720p@30FPS, 720p@25FPSAHD: 5Mpx, 4Mpx, 1080p @25FPS, 720p@30FPS, 720p@25FPSHDCVI: 4Mpx, 1080p @30FPS, 720p@30FPS, 720p@2 |
| Main Stream coding | 8Mpx@8 FPS; 5Mpx@12 FPS; 4Mpx @15 FPS; 3Mpx@18 FPS; 1080p /720p/WD1/4CIF/VGA/CIF@25 FPS(P) |
| Extra Stream coding | WD1 / 4CIF / CIF (25 FPS) |
| Video Bit Rate | 32 Kbps at 10 Mbps |
| Simultaneous multifunction | Pentaplex: Live, Recording, Playback, Backup and Remote Access |
| Alarms | 16 Inputs / 4 Outputs |
| Motion Detection | Motion detection 2.0: Deep-learning based motion detection, can classify humans and vehicles upon motion detection.Enabled by default on all analog channels.* Motion detection and AcuSense cannot be e |
| Artificial intelligence | Acusense: Perimeter protection based on VCA rules with false alarm filter for human and vehicle detection applied on: Line Crossing and Area Intrusion.Available in up to 4 analog video channels.* Mot |
| Recording method | Manual, programmed, motion detection |
| Internal memory | 2 HDD SATA 3.5" of up to 10 TB each (not included) |
| Communication | 2 x USB (Mouse and backup) / Remote control / RJ45 (Ethernet) 10/100/1000M / RS-485 half-duplex |
| Remote connections | 128 |
| Remote access | Web Browser, Hik-Connect Smartphone App, PC Software iVMS-4200 and Hik-Central |
| Network protocol | TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF |
| Racking | 1U |
| Power | DC 12 V, ? 19 W (without HDD) |
| Operating temperature | -10° ~ +55° C |
| Dimensions | 384(W) x 317(D) x 52(H) mm |
| Weight | ? 2 Kg (without HDD) |
