| Brand | V-SOL |
| Interface | 1X PON 4x LAN RJ45 10/100/1000Mbps 1x RJ11 ( FXS ) |
| PON | XPON Port (EPON PX20+ and GPON Class B+)Single-mode SC, SC/UPC connectorOptical transmission power: 0 to +4 dBmReceiving sensitivity: -27 dBmOptical overload power: -3 dBm (EPON) o -8 dBm (GPON)Transm |
| WiFi Antennas | Complies with IEEE802.11b/g/nWi-Fi: 2,4 GHz 2x2, speed up to 300 MbpsTransmission power: 2,4 GHz: 17 dBm |
| WiFi functions | 802.11b/g/n integratedAuthentication: WAP-PSK (TKIP)/WAP2-PSK (AES) |
| Management Protocols | OAM/OMCI/Telnet/Web/TR069Supports full management of HGU functions via VSOL OLT |
| Layer functions 2 ( switching ) | Compatible with bridge 802.1D and 802.1ad, VLAN 802.1Q |
| Layer functions 3 ( routing ) | IPv4, IPv6 and IPv4/IPv6 dual stackDHCP/PPPOE/StaticDHCP server and clientNAT/DMZ/DDNS |
| Multicast | IGMP v1/v2/v3, IGMP eavesdropping |
| Security | Loop detection, flow and storm control support |
| Voip | SIP and IMS SIPCodecs G.711a/G.711u/G.722/G.729Echo cancellation, VAD/CNG, DTMF RetransmissionFAX T.30/T.38Caller ID/Call Waiting/Call Forwarding/Call Transfer/Call Hold/Conference Three-Way Conferenc |
| Colour | White |
| Dimensions | 205mm x 140mm x 37mm |
| Weight | 340g |
| Temp. operation | 0o C ~ +55o C |
| Power | DC 12V 1A (adapter included) |
The HG325N (4GE+1POTS+WiFi 4 XPON HGU ONT) is a broadband access device specially designed to meet the needs of fixed network operators in FTTH and triple play services.
The ONT is based on high-performance chip solutions, supports dual-mode XPON technology (EPON and GPON), as well as IEEE802.11b/g/n Wi-Fi 4 technology and other layered 2/capa 3, functions providing data services for carrier-grade FTTH applications. In addition, the ONT also supports the OAM/OMCI protocol, and allows configuring or managing various ONT services on the VSOL OLT.
The ONT offers high reliability, is easy to manage and maintain, and has quality of service (QoS) guarantees for various services. Complies with various international technical standards, such as IEEE802.3ah and ITU-T G.984.
