| Brand | X-Security |
| Image sensor | 1/2.8" STARVIS™ CMOS |
| Resolution | 4 Megapixel (2560 × 1440) |
| Lens | Varifocal 5 ~ 125 mm (Optical zoom 25X) Auto Iris, Auto Focus |
| Digital zoom | 25 X |
| Infrared lighting | Range 100m |
| Range performance | 2500 (D), 987,5 (O), 500 (R), 250 (I) |
| Compression | H.264H; H.264B; Smart H.265+; H.264; H.265; MJPEG(Sub Stream); Smart H.264+ |
| Main Stream rate | 4M/3M/1080p/1.3M/720p @(1–25/30 fps) |
| Extra Stream rate | D1/CIF@ (1–25/30 fps) |
| Bitrate | H264: 96–14.848 Kbps H265: 38–8.960 Kbps |
| Image improvements | WDR (120dB),2D/ 3DNR, HLC, BLC, ATW, AGC, Privacy Mask |
| Minimum illumination | Colour: 0.005 lux@F1.6B/W: 0.0005 lux@F1.60 lux@F1.6 (IR light on) |
| SMD 4.0 | Integrated |
| Quick Pick | Integrated |
| IVS (Perimeter protection) | Tripwire; intrusion; cross-fence detection; loitering detection; abandoned/lost object; fast motion; parking detection; people gathering; vehicle/human alarm classification |
| Face detection | Supports face detection, optimization, tracking, image capture, high quality facial snapshot uploading and facial enhancement; Supports attribute extraction. 6 attributes and 8 expressions: Gender, ag |
| Audio | 1 Input / 1 Output |
| Audio Compression | PCM; G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1; G729; G723 |
| Day / Night | Removable mechanical ICR filter |
| Network interface | Ethernet 10/100 BaseT |
| Remote access | WEB interface, CMS software, mobile application and NVR |
| Memory | Slot for Micro SD card (Max 256 GB) |
| Pan/Tilt Range | Overview: 0° to 360° without endInclination: –15° to +90°, automatic rotation 180°auto flip 180° |
| Manual speed | Turn: 0,1°–200°/s Inclination: 0,1°–120°/s |
| Speed between Presets | Turn: 240°/s Inclination: 200°/s |
| Preset positions | 300, 5 auto pattern, 8 auto tour, 5 auto scan |
| Communication | RTMP; CGI; SDK; ONVIF (Profile S&G&T); P2P |
| Alarms | 2 inputs / 1 relay NO/NC |
| Power | DC 12 V / 3 A, PoE+(802.3at) |
| Degree of protection | IP66, TVS 6000 V lightning-proof; surge protection; transient voltage protection |
| Temp. operation | -40o C ~ +70o C |
| Dimensions | 270,4 mm (H) x 160 (O) mm |
| Weight | 2.4 kg |
