| Model | DA5060 |
| Rated output power | 5x60W |
| Power per channel (RMS) | 60W RMS (@100V)60W RMS (@4?)34W RMS (@8?)18W RMS (@16?) |
| Power | 170 ~ 264V AC, 50/60Hz |
| Fusible | T5AL (250V) |
| Ports | Inputs:1 x Power1 x balanced XLR (for connection to microphone)5 x LINE IN (unbalanced RCA) 5 x LINE IN (Phoenix balanced 3EDG))1 x AUX (balanced RCA)Outputs:5 x Euroblock (100V)5 x Euroblock (4?) |
| Input sensitivity | - MIC: -24dBV - LINE / AUX: -10dBV |
| Frequency response | - MIC: 100Hz ~ 17kHz- LINE: 100Hz ~ 22kHz- AUX: 100 ~ 22kHz |
| Distortion | 1% |
| SNR (Signal to Noise Ratio) | - MIC: 75dB- LINE: 80dB |
| Dimensions | 482mm (W) x 44mm (H) x 302mm (D)1U |
| Weight | 8.1kg |
| Other | - On/Off button- Bass and treble control potentiometers of the microphone signal- Bass and treble control potentiometers of the output signal- Mic signal gain control potentiometer- LED indicator of o |
A mixer amplifier is a compact device that combines the functions of an audio mixer and an amplifier. Allows multiple sound sources to be connected and their volume levels individually adjusted before mixing them into a single output signal. Its compact design makes it ideal for small space applications or simple installations where a complex audio system is not required.
This type of equipment is commonly used in meeting rooms, small churches, classrooms, stores or public address systems, where several audio signals need to be amplified at the same time.
