| Mounting | Surface |
| Opening mode | Fail Safe (NC) |
| Type of opening | Bidirectional (for double door) |
| Locking delay time | 0, 3, 6 y 9 seconds |
| LED status indicator | Green (unlocked) / Red (locked) |
| Retention force | 1000 Kg |
| Power | DC 12 V / 1 A max. (x2) (start) / 0.18 A max. (x2) (idle) |
| Door sensor | NO / COM |
| Plate dimensions | 45 (W) x 428 (H) x 35 (D) mm |
| Dimensions of the socket | 35 (An) x 204 (Al) x 35 (Fo) mm (x2) |
| Temp. operating | -40o C ~ +60o C |
| Weight | 1.8 Kg |
| Range | EasyAccess |
