| Mounting | Built-in |
| Opening mode | Fail Safe (NC) |
| Locking delay time | 0, 3, 6 y 9 seconds |
| Retention force | 1000 Kg |
| Power | DC 12 V / 960 mA máx. (start) / 180 mA max. (rest) |
| Open sensor | LED indicator and door indicator output (integrated in socket) |
| Entrance profile | Narrow 25mm |
| Plate dimensions | 192 (H) x 25 (W) x 37 (D) mm |
| Dimensions of the socket | 90 (H) x 25 (W) x 2 (H) mm |
| Temp. operating | -40o C ~ +60o C |
| Weight | 680 g |
