| Operating system | Operating system ADPRO® XO™ Security, based on Linux |
| Video output | HDMI (2): HDMI x 1 (4K Max), VGA x 1 (1080p) |
| Video compression | H.264/H.265 (H.265 compatible with Hikvision, Honeywell, ONVIF S/T profile and generic controller) |
| Video Resolution | Up to 4K resolution; For optimal performance, when using 4K cameras on XO devices, the number of supported cameras and analysis channels (IntrusionTrace and/or LoiterTrace) are reduced in proportion t |
| Images/second | Full HD/1080p to 25/30 fps (PAL/NTSC) |
| Bandwidth (video) | 16 x 5 Mbps |
| Bandwidth Management | Configurable bitrate constant or variable / Configurable bandwidth limiter |
| Audio input | Audio input from compatible IP camera |
| Audio output | Analog audio output ( 3,5 mm connector) and digital audio output from IP cameras. Support for zone-specific audio |
| Built-in inputs | 6 inputs in the box |
| External inputs | Up to 128 inputs through Ethernet I/O units. |
| Relay outputs | 2 outputs in the box |
| External relay outputs | Up to 128 Relay outputs via Ethernet I/O units. |
| Web server | XO client - integrated web client application (ActiveX) |
| SATA / Max HDD Storage. | 2 TB / 2 x 10TB |
| Ethernet network | 2 x RJ45: Self-adapting Ethernet interfaces 10M/100M/1000M |
| PoE Support | 8 PoE ports |
| Recording Type | Schedule/Detection/Event |
| IP Camera Integration | Driver específico según la marca, genérico o driver ONVIF Perfil S/T (Depende de la cámara) |
| Management | Web client interface (XO client), ADPRO VideoCentral Platinum, third-party software (SDK available) and iTrace App for iOS/Android |
| Power supply | 100-240 VAC 50/60Hz |
| Power consumption | Max. 180W; 15W no hard drivePower PoE ports: 130W max. (30W max. per port) |
| Operating temperature | from -10°C to 55°C |
| Humidity | less than 90% relative humidity without condensation |
| Warranty | 2 years |
| Dimensions (length x width x height) | 372mm × 313,3mm × 46,5mm |
| 19" Compatible bracket | Yes |
| Video analysis | Basic: Motion detection, Manipulation Up to 8 xTrace Analytics channels: IntrusionTrace™, LoiterTrace™ (requires optional licenses) |
