| Brand | X-Security |
| Video format | HDTVI / HDCVI / AHD / CVBS / IP |
| Video inputs | 16 BNC Channels: HDTVI: Up to 5Mpx HDCVI: Up to 4K AHD: Up to 5Mpx CVBS |
| Hybrid configuration | Up to 32 IP Channels (8Mpx), replacing all the BNC channels |
| Video outputs | 1 HDMI Full HD, 1 VGA |
| Audio inputs | 1 Channel RCA |
| Audio outputs | 1 Channel RCA |
| Bidirectional audio | Reusing the audio input/output |
| Supports audio | Over coax |
| Video compression | H.265+; H.265; H.264+;H.264 |
| Display resolution | 3840x2160, 2560x1440, 1920x1080, 1280x1024, 1280x720, 1024x768 |
| Total bandwidth | 96 Mbps |
| Recording resolution | 4K / 6Mp / 5Mp / 4Mp / 3Mp / 1080p / 1080N / 720p |
| Main Stream coding | All channels 4K@ (1-7 fps); 6 MP@ (1-10 fps); 5 MP @ (1-12 fps); 4K-N/4 MP/3 MP@ (1-15 fps); 4M-N/1080P/720P/960H/D1/CIF (1 fps–25/30 fps); |
| Extra Stream coding | 960H@ (1 fps–15 fps); D1/CIF@ (1 fps–25/30 fps) |
| Simultaneous multifunction | Pentaplex: Live, Recording, Playback, Backup and Remote Access |
| Alarms | Does not have |
| AI Weapons | Face detection, face recognition, perimeter protection |
| Video analysis | VCA: Tripwire | Area intrusion | Abandoned object | Face detection |
| Recording method | Manual, programmed, motion detection, alarm |
| Backup | USB (Memory, HDD, CD-RW, DVR-RW) / Network |
| Internal memory | 1 SATA HDD up to 8 TB |
| Communication | RS485 (PTZ) / 2 x USB (Mouse and backup) / RJ45 10/100 (Ethernet) |
| Remote access | Web browser (ActiveX), mobile phone application or PSS software |
| Power | DC 12 V / 3 A |
| Dimensions / weight | 55 (H) x 325 (W) x 255 (D) mm / 2 Kg |
