| Brand | X-Security |
| Inputs for IP cameras | LAN port up to 32 channels |
| PoE | 16 PoE ports IEEE802.3at/af |
| IP compatible cameras | X-SECURITY (proprietary protocol), ONVIF |
| Video outputs | 1 HDMI 4K, 1 VGA |
| Video compression format | H.265+ Smart / H.265 / H.264+ / H.264 / MJPEG |
| Bidirectional audio | 1 input, 1 output, RCA |
| Recording resolution | 16MP, 12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080p, 960p, 720p, D1, VAT |
| Decoding capacity | AI Disabled:2CH to 16MP@30FPS, 2CH to 12MP@30FPS, 4CH to 8MP@30FPS, 4CH to 6MP@30FPS, 6CH to 5MP@30FPS, 8CH to 4MP@30FPS, 12CH to 1080p@30FPS, 16CH to 720p@30FPS, 32CH to D1@30FPSAI Enabled:1CH to 16M |
| Video output | 1 HDMI up to 4K1 VGA up to 1080P |
| Display resolution | HDMI: 3840×2160, 1920×1080, 1280×1024, 1280×720VGA: 1920x1080, 1280×1024, 1280×720*HDMI and VGA output can be configured simultaneously or separately |
| Bandwidth | AI Disabled:256 Input Mbps / 256 Output MbpsAI Enabled:180 Input Mbps / 180 Output Mbps |
| SMD (Advanced Motion Detection) | Advanced motion detection based on human- and vehicle-induced pixel shift reducing false alarmsBy NVR: Up to 4CH Per IP camera with SMD: All channels (Up to 16 targets/second) |
| IVS Perimeter Protection | Intelligent algorithm based on human and vehicle detection with high accuracy filtering out any objects of no interest in the environment such as rain, leaves, bright lights, etc. IVS is based on line |
| Facial Detection | Detection of facial attributes such as: Gender, age group, eyeglasses, expressions, mask or beardFor the NVR: Up to 1CH (Up to 12 frames/second per channel)By IP camera with Face Detection: All channe |
| Facial Recognition | Up to 10 face databases with 20.000 images (2.5G)By NVR: - Up to 8CH using Face Detection cameras - Up to 1CH using the NVR itselfBy IP camera with facial recognition: All channels |
| QuickPick | Rapid target search for humans and vehicles over live video or recording based on SMD detections |
| Intelligent event searches | SMD, IVS, Face Detection, Face Recognition, ANPR, People Counting, Heat Mapping |
| Simultaneous multifunction | Pentaplex: Live, Recording, Playback, Backup and Remote Access |
| Alarms | 4 Inputs / 2 Outputs NO/NC |
| Audio | 1 Input RCA / 1 Output RCA |
| Recording method | Manual, programmed, motion detection, alarm |
| Backup | USB (Memory, HDD, CD-RW, DVR-RW) / Network / SATA |
| Internal memory | 2 HDD SATA 3.5" of up to 16TB (not included) |
| Communication | 2x USB (Mouse and backup) / 1xRS232 / 1 RJ45 10/100/1000M (Ethernet) |
| Racking | 1U |
| Remote access | Browser (ActiveX), Mobile phone application, DSS or DSS PRO software |
| Power | AC 100~240 V, 50/60 Hz, >10W |
| Operating temperature | –10 °C to +55 °C, 10%-93% (RH, non-condensing) |
| Dimensions | 53 (H) x 375 (W) x 329.3 (D) mm / 2.6 Kg |
