| Brand | X-Security |
| Thermal sensor | 160x120 Vanadium oxide |
| Optical sensor | 1/2.8” Progressive Scan CMOS 2 Megapixel |
| Main Stream rate | 1280x960 (25fps) Therm / 1920x1080 (25fps) Opt |
| Extra Stream rate | 640x480 (25fps) Therm / 704x480 (25fps) Opt |
| Compression | H.265 / H.264 / MJPEG |
| Lens | 7 mm (Therm) / 8 mm (Opt) |
| Viewing angle | 56°×44° (Term) / 86.2°×45.9° (Opt) |
| Thermal sensitivity | < 50mK (0.05 o C) |
| Temperature measurement | No |
| Spectral range | 8~14µm |
| Pitch detector | 12µm |
| VCA | IVS rules (cross line, intrusion, area entry and exit) |
| Rules for fire | Up to 4 regions of fire detection |
| Intelligent functions | Detection of fire and alarm, line crossing, intrusion |
| smart improvements | DWDR, 3DNR, BLC, HLC AGC, ROI, Privacy Mask |
| Audio | 1 Input / 1 Output |
| Alarm | 2/2 In/Out |
| Internal memory | Micro SD card up to 256GB |
| Network interface | Ethernet 10/100 BaseT |
| Remote access | WEB, CMS (DSS/PSS), Smartphone and NVR interface |
| Interoperability | ONVIF |
| Power | 12VDC, PoE IEEE802.3at |
| Temp. operation | -30o C ~ +55o C |
| Degree of protection | Weatherproof IP67 |
| Dimensions | 238.6 mm (D) x 90.4 (O) mm |
| Weight | 1000 g |
