| Brand | X-Security |
| Image sensor | 1/2.9” Progressive CMOS |
| Maximum resolution | 4 Megapixel (2688x1520) |
| Main Stream rate | 2688 × 1520 @ (1–25/30) fps |
| Extra Stream rate | 704 × 576 @ (1–25 fps)/704 × 480 @ (1–30 fps) |
| Compression | H.265+/H.265/H.264+/H.264 |
| Lens | 2.7 ~ 13.5 mm (H: 104o-29o)(V:54o-16o)(D:125o-33o) |
| Minimum illumination | 0.006 lux@F1.5 (Colour, 30IRE)0.0006 lux@F1.5 (B/W, 30IRE)0 lux (Illuminator on) |
| Image improvements | WDR 120dB, BLC, HLC, AWB, AGC, 3D-NR, ROI , Smart IR |
| IVS (Perimeter protection) | Intrusion, tripwire (both functions support classification and accurate detection of vehicles and persons) |
| Intelligent search | Work together with Smart NVR to refine intelligent search, event extraction and merging with event videos |
| SMD Plus | Integrated |
| Day / Night | Removable mechanical ICR filter |
| Network interface | Ethernet 10/100 BaseT |
| Audio | Integrated microphone |
| Remote access | WEB, CMS (DSS/PSS), Smartphone and NVR interface |
| Interoperability | ONVIF (Profile S/Profile T); CGI; P2P; Milestone |
| Power | DC 12 V / 2.8 W, PoE IEEE802.3af |
| Temp. operation | -30o C ~ +60o C |
| Degree of protection | Weatherproof IP67 |
| Dimensions | 108,3 mm (D) x 122 (O) mm |
| Weight | 715 g |
| Color | Black |
