| Brand | X-Security |
| Image sensor | 1/2.7” Progressive CMOS |
| Maximum resolution | 8 Megapixel (3840X2160) |
| Main Stream rate | 3840x2160 @ (1~20) fps2688x1520@ (1~25/30) fps |
| Extra Stream rate | 704×576 @(1~25 fps)704×480 @ (1~30 fps) |
| Compression | H.265+/H.264+/H.265/H.264/H.264H/H.264B |
| Video bitrate | H.264: 32 kbps–8192 kbps H.265: 12 kbps–8192 kbps |
| Lens | 2.8 mm |
| Viewing Angle (FOV) | H: 111o, V: 58o, D: 132o |
| Range performance | 84.8 m (D), 33.9 m (O), 17 m (R), 8.5 m (I) |
| Electronic Shutter | 1/3 s~1/100.000 s |
| Minimum illumination | 0.008 Lux @(F1.6, AGC ON)0 lux (Illuminator on) |
| Supplementary lighting | Dual Light:IR Range 30 mWhite light range 30 m |
| Day / Night | Removable mechanical ICR filter |
| Image improvements | WDR (120 dB), BLC, HLC, AWB, AGC, 3D-NR, ROI , Mirror effect, Privacy masking, Image rotation 0°/90°/180°/270° |
| IVS (Perimeter protection) | Intrusion, tripwire (both functions support classification and accurate detection of vehicles and persons) |
| SMD (Smart Motion Detection) | Work together with Smart NVR to refine intelligent search, event extraction and merging with event videos |
| Audio | Integrated microphone |
| Audio Compression | G.711a; G.711Mu; PCM; G.726 |
| Internal memory | MicroSD card slot up to 256 GB |
| Remote access | WEB, CMS (DSS/PSS), Smartphone and NVR interface |
| Network interface | Ethernet 10/100 BaseT |
| Interoperability | ONVIF (Profile S/Profile T); CGI; P2P; Milestone |
| Power | DC 12V / 3.3WPoE IEEE802.3af |
| Temp. operation | -40o C ~ 55o C |
| Degree of protection | Weatherproof IP67 |
| Material | Body: MetallicCover: Plastic |
| Dimensions | 100.9 mm (D) x 109.9 (O) mm |
| Base dimensions | O base 109.9 mm / O between bolts 84 mm / 3 bolts |
| Weight | 380 g |
| Colour | Black |
