| Brand | X-Security |
| Image sensor | 1/2.8" CMOS |
| Resolution | 4 Megapixel (2560x1440) |
| Optical zoom | 45X |
| Digital zoom | x16 |
| Lens | Varifocal 3.95 ~ 177.75 mm (H: 65.7°–1.9°V: 39.4°–1.1°D: 73.1°–2.1°) |
| Compression | H.264H; H.264B; Smart H.265+; H.264; H.265; MJPEG (Sub Stream); Smart H.264+ |
| Main Stream rate | 4M / 3M / 1080p / 1.3M / 720p (1-25/30 fps) |
| Extra Stream rate | D1 / VGA / CIF (1-25/30 fps) Sub stream 2: 1080p / 1.3M / 720p (1-25/30 fps) |
| Bitrate | H264: 96 kbps–14848 kbps H265: 38 kbps–8960 kbps |
| Speed between Presets | Horizontal: 300° /s, Vertical: 200° /s |
| Preset positions | 300, 5 auto pattern, 8 auto tour, 5 auto scan |
| Image improvements | WDR (120dB),2D/ 3DNR, HLC, BLC, ATW, AGC, Privacy Mask, ROI |
| Minimum illumination | Colour: 0.005 Lux@F1.6B/W: 0,0005 Lux@F1,60 Lux@F1.6 (IR activated) |
| IR light | 250m |
| Day / Night | Removable mechanical ICR filter |
| IVS (Perimeter protection) | Tripwire; intrusion; fence climbing; loitering detection; abandoned/lost object; fast movement; parking detection; people gathering; vehicle/person alarm classification; Linkage tracking |
| Face detection | Supports face detection, optimization, tracking, image capture, high quality facial snapshot uploading and facial enhancement; Supports attribute extraction. 6 attributes and 8 expressions: Gender, ag |
| Auto-tracking 3.0 | YES |
| SMD | Yes |
| Analogue output | 1 channel (CVBS output, BNC) RS-485 |
| Audio | 1 Input (Line In) / 1 Output (Line Out) |
| Alarms | 7 inputs / 2 relay |
| Network interface | Ethernet 10/100 BaseT |
| Remote access | WEB interface, CMS software, mobile application and NVR |
| Memory | Slot for Micro SD card (Max 512 GB) |
| Communication | CGI; SDK; ONVIF (S&G&T Profile); P2P |
| Protection | IP67; IK10; TVS 8000V lightning-proof; surge protection; transient voltage protection |
| Power | AC 24 V / 2.5 A , PoE+(802.3at) |
| Degree of protection | Weatherproof IP67, Anti-vandal IK10 |
| Temp. operation | -40o C ~ +70o C |
| Dimensions | 337.4 mm (H) x 209 (O) mm |
| Weight | 5900 g |
