| Brand | X-Security |
| Image sensor | 1/2.8” CMOS |
| Resolution | 1080P(1920x1080), 720P(1280x720), D1(704x576), CIF(352x288) |
| Compression | H.265+/H.265/H.264+/H.264 |
| Main Stream rate | 1080p (1~25FPS) / 720p(1~50FPS) |
| Extra Stream rate | 2o: D1/CIF (1 ~ 25 FPS), 3o: 720p/D1/CIF (1 ~ 25 FPS) |
| Bitrate | 25 Kbps ~ 6400 Kbps (H265) |
| Lens | 5 ~ 80 mm (Optical Zoom 16X) Auto Focus |
| Infrared range | 100 m |
| Minimum illumination | 0.005 Lux (colour) / 0.0005 Lux (B/N) |
| Image improvements | WDR (120dB), 3DNR, HLC, BLC, AGC, Privacy Mask, Smart Motion Detection (SMD) |
| IVS intelligent detection | Tripwire, Perimeter, Lost/Abandoned object |
| Day / Night | Removable mechanical ICR filter |
| Network interface | Ethernet 10/100 BaseT |
| Remote access | WEB interface, CMS software, mobile application and NVR |
| Memory | Slot for Micro SD card (Max 512 GB) |
| Autotracking | Included |
| Autopatrol | Activates the IVS rule when it detects a target and causes the camera to link with the PTZ to rotate to the target position and patrol according to your presets. |
| Face detection | Autotracking is available and can be activated |
| Pan/Tilt Range | Horizontal: 0°~360°, Vertical: -5°~90°, Auto flip 180° |
| Manual speed | Horizontal: 0.1°~240° /s, Vertical: 0.1°~160° /s |
| Speed between Presets | Horizontal: 240° /s, Vertical: 160° /s |
| Preset positions | 300, 5 auto pattern, 8 auto tour, auto pan, 5 auto scan |
| Communication | DH-SD, ONVIF Compatible |
| Alarms | 2 inputs / 1 relay NO/NC |
| Audio | 1 Input (Line In) / 1 Output (Line Out) |
| Power | AC 12 V / 2 A , PoE+ IEEE802.3at |
| Degree of protection | IP66 |
| Temp. operation | -40o C ~ +60o C |
| Dimensions | 170.4 mm (H) x 171 (O) mm |
| Weight | 3200 g |
