| Brand | X-Security |
| Range | ULTRA |
| Image sensor | 1/2.8“ Progressive Scan CMOS |
| Resolution | PTZ: 4 Megapixel (2560×1440)Panoramic: 4 Megapixel (2560×1440) |
| Main Stream rate | 4MPx/ 3MPx/ 1080p/ 1.3MPx/ 720p @(1~25/30 fps) |
| Extra Stream Rate 1 | D1/ CIF/ VGA @(1~25/30 fps) |
| Extra Stream Rate 2 | 1080p/ 1.3MPx/ 720p @(1~25/30 fps) |
| Minimum illumination | PTZ: 0.005 lux Color@(F1.6, AGC ON) / 0 lux with Dual LightIR range: 100 mWhite light range: 50 mPanoramic: 0.001 lux Color@(F1.6, AGC ON) / 0 lux with Dual LightIR range: 30 mWhite light range: 30 mS |
| Compression | H.265+/ H.264+/ H.265/ H.264/ H.264H/ H.264B |
| Bitrate | H264: 96 Kbps~14848 KbpsH265: 38 Kbps~8960 Kbps |
| Lens | PTZ: Varifocal 5~125 mm (Optical Zoom 25X)Panoramic: 2.8 mm |
| Viewing Angle (FOV) | PTZ: H: 51.9~3o, V: 39.7o~2.2o, D: 63.1o~3.7oOverview: H: 101o, V: 53o, D: 120o |
| Range performance | 2500 m (D), 987.5 (O), 500 (R), 250 (I) |
| Digital zoom | 16x |
| Electronic Shutter | PTZ: 1~1/30.000 sPanoramic: 1/3~1/100.000 s |
| Day / Night | Removable mechanical ICR filter |
| Auto Focus | Semi-auto, Manual or Auto |
| Image improvements | WDR (120 dB), BLC, HLC, 2D/3D-DNR, AGC, AWB, Privacy Masking, ROI, Flip |
| EIS (Image Stabilizer) | Yes |
| SMD (Smart Motion Detection) | Advanced SMD motion detection 4.0 |
| IVS (Perimeter protection) | Intrusion, tripwire (both functions support the accurate classification and detection of vehicles and persons) |
| Pan/Tilt Range | PTZ: Horizontal: 360°, Vertical: -15°~90° auto flip 180oPanoramic: Horizontal: 13~23o |
| Manual speed | Horizontal: 0.1~ 200°/s, Vertical: 0.1~120°/s |
| Speed between Presets | Horizontal: 240°/s, Vertical: 200°/s |
| Preset positions | 300 preset, 5 auto pattern, 8 auto tour, auto pan, auto scan |
| Autotracking | YES |
| Internal memory | MicroSD card slot up to 512 GB |
| Alarms | 2 IN / 1 OUT |
| Active Deterrence | Siren and strobe flash integrated in the cameraRed and blue lightFlash duration: 5~30 sIt has 11 alarm sounds |
| Audio | 1 Input / 1 Output |
| Audio Compression | PCM; G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1; G729; G723 |
| PTZ Control | Through network access |
| Network interface | Ethernet 10 / 100 BaseT |
| Remote access | WEB, CMS (DMSS/DSS Pro), Smartphone and NVR interface |
| Interoperability | ONVIF (S-profile, G-profile, T-profile), CGI, SDK |
| Power | DC 12 V, max. 25 WPoE+ (IEEE802.3at) |
| Temp. operation | -40o C ~ +65o C |
| Degree of protection | Waterproof IP66 / Overvoltage protection 6000 V |
| Dimensions (without bracket) | 304.6 mm (H) x 160 mm (D) x 184.4 mm (W) |
| Weight (without bracket) | 3.41 kg |
