| Brand | X-Security |
| Image sensor | 1/2.8” STARVIS CMOS |
| Maximum resolution | 4 Megapixel (2560 × 1440) |
| Lens | Motorised vari-focal 2.8~ 12mm (H: 90.3°–29.4°; V: 48,5°–16,6°; D: 105.7°–33.6°) |
| Optical zoom | 4X |
| Digital zoom | 16x |
| Main Stream rate | 4M/3M/1080p/1.3M/720p@(1–25/30fps) |
| Extra Stream rate | D1/VGA/CIF@(1–25/30 fps) |
| Compression | H.264H; H.264B; Smart H.265+; H.264; H.265; MJPEG (Sub Stream); Smart H.264+ |
| Bitrate | H.264: 2816Kbps - 13056Kbps H.265: 1024Kbps - 7936Kbp |
| Minimum illumination | Colour: 0.005 lux@F1.6B/W: 0.0005 lux@F1.6 |
| Image improvements | dWDR, BLC, HLC, AWB, AGC, 2D/3D-NR, Privacy Masking |
| Network interface | Ethernet 10/100 BaseT |
| Pan/Tilt Range | Horizontal: 0°~355°, Vertical: 0°~90° auto flip 180° |
| Manual speed | Horizontal: 0.1°~100° /s, Vertical: 0.1°~60° /s |
| Speed between Presets | Horizontal: 100° /s, Vertical: 60° /s |
| Preset positions | 300, 8 Tour, Auto Scan |
| Face detection | Supports face detection, face tracking, snapshots and face enhancement;Supports facial trimming: face, one inch photo;Capture strategies include real-time capture and quality first. |
| IVS (Perimeter protection) | Tripwire; intrusion; cross-fence detection; loitering detection; abandoned/lost object; fast motion; parking detection; people gathering; vehicle/human alarm classification |
| SMD | Yes |
| Internal memory | MicroSD card slot up to 512 GB |
| Remote access | Web browser, CMS Software (DSS/PSS), Smartphone (DMSS) and NVR |
| Interoperability | ONVIF (S&G&T profile); P2P; .CGI; SDK |
| Power | DC 12 V / 6.1 W, PoE(802.3af) |
| Degree of protection | Weatherproof IP66, Anti-vandal IK10 |
| Temp. operation | -30o C ~ +60o C |
| Dimensions | 89 mm (H) x 122 (O) mm |
| Weight | 500 g |
