| Brand | X-Security |
| Image sensor | 1/2.8" Progressive Scan CMOS |
| Resolution | 4 Megapixel (2560x1440) |
| Lens | Varifocal 5~125 mm (optical zoom 25x)) |
| Viewing Angle (FOV) | H: 51.9o~3o, V: 39.7o~2.2o, D: 63.1o~3.7o |
| Range performance | 2500 m (D), 987.5 m (O), 500 m (R), 250 m (I) |
| Focus | Auto; semi-auto; manual |
| Digital zoom | 16x |
| Electronic Shutter | 1 s~1/30.000 s |
| Minimum illumination | 0.005 Lux @(F1.6, AGC ON)0 lux with IR range 100 m |
| Supplementary lighting | Dual light (IR + white light)IR range of 100 mWhite light range 50 m |
| Day / Night | Removable mechanical ICR filter |
| Compression | H.264H; H.264B; Smart H.265+; H.264; H.265; MJPEG (ExtraStream); Smart H.264+ |
| Main Stream rate | 4Mpx/3Mpx/1080p/1.3Mps/720p @(1–25/30 fps) |
| Extra Stream Rate 1 | D1/VGA/CIF @(1–25/30 fps) |
| Extra Stream Rate 2 | 1080p/1.3Mpx/720p @(1–25/30 fps) |
| Bitrate | H264: 96 Kbps~14848 KbpsH265: 38 Kbps~8960 Kbps |
| Image improvements | WDR (120dB), 2D/ 3DNR, HLC, BLC, ATW, AGC, ROI, Rotation 180o, Privacy masking |
| Motion Detection | Yes |
| EIS (Image Stabilizer) | Yes |
| SMD (Smart Motion Detection) | SMD 4.0, advanced motion detectionDahua Smart Motion Detection technology works with intelligent algorithms to classify targets that trigger motion detection alarms. Filters out non-target objects, su |
| IVS (Perimeter protection) | Tripwire; intrusion; fence crossing detection; loitering detection; abandoned/lost object; fast movement; parking detection; people gathering; vehicle/human alarm classificationAutomatically filters o |
| Face detection | Supports face detection, image captures, and face enhancement. Supports face trimming: face, one inch photo.Capture strategies include real-time capture and quality prioritization. |
| Audio | 1 Input / 1 Output |
| Audio Compression | PCM; G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1; G729; G723 |
| Alarms | 2 inputs/ 1 outputs |
| Internal memory | MicroSD card slot up to 512 GB |
| Pan/Tilt Range | Horizontal: 0°~360° no endVertical: -15°~90°, with auto flip 180° |
| Manual speed | Horizontal: 0.1°~200°/s Vertical: 0.1°–120°/s |
| Speed between Presets | Horizontal: 240°/s Vertical: 200°/s |
| Preset positions | 300, 8 tour, 5 Pattern, 5 Scan |
| Auto Tracking | Yes |
| Communication | ONVIF (profile S, G, T), CGI, SDK, P2P |
| Network interface | Ethernet 10/100 BaseT |
| Remote access | WEB, CMS (DSS/PSS), Smartphone and NVR interface |
| Power | DC 12 V / 3 A, max. 13 WPoE+ (IEEE802.3at) |
| Temp. operation | -40o C ~ +65o C |
| Degree of protection | Weatherproof IP66Surge protection 6000 V |
| Dimensions | 269.9 mm (H) x 160 (O) mm |
| Weight | 2.6 kg |
