| Brand | X-Security |
| Image sensor | 1/2.8" Progressive Scan CMOS |
| Resolution | 4 Megapixel (2560x1440) |
| Lens | Varifocal 2.7~13.5 mm (optical zoom 5x)) |
| Viewing Angle (FOV) | H: 94.9o~30.1o, V: 51o~17.1o, D: 112.3o~34.6o |
| Range performance | 270 m (D), 106.6 m (O), 54 m (R), 27 m (I) |
| Focus | Auto; semi-auto; manual |
| Digital zoom | 16x |
| Electronic Shutter | 1 s~1/30.000 s |
| Minimum illumination | 0.005 Lux @(F1.6, AGC ON)0 lux with IR range 50 m |
| Supplementary lighting | Dual light (IR + white light)IR range of 50 mWhite light range 30 m |
| Day / Night | Removable mechanical ICR filter |
| Compression | H.264H; H.264B; Smart H.265+; H.264; H.265; MJPEG (ExtraStream); Smart H.264+ |
| Main Stream rate | 4Mpx/3Mpx/1080p/1.3Mps/720p @(1–25/30 fps) |
| Extra Stream Rate 1 | D1/VGA/CIF @(1–25/30 fps) |
| Extra Stream Rate 2 | 720p @(1–25/30 fps) |
| Bitrate | H264: 96 Kbps~14848 KbpsH265: 38 Kbps~8960 Kbps |
| Image improvements | WDR (120dB), 2D/ 3DNR, HLC, BLC, ATW, AGC, ROI, Rotation 180o |
| Motion Detection | Yes |
| EIS (Image Stabilizer) | Yes |
| SMD (Smart Motion Detection) | SMD 3.0, advanced motion detection |
| IVS (Perimeter protection) | Tripwire; intrusion; fence crossing detection; loitering detection; abandoned/lost object; fast movement; parking detection; people gathering; vehicle/human alarm classification |
| Audio | Built-in microphone and speaker |
| Audio Compression | G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1; PCM |
| Deterrent alarm | White deterrent lightFlash duration: 5~30 sFlash frequency: high, medium, low.Deterrent sirenOffers 11 alarm sound types, and supports importing up to 10 custom sounds. The alarm sound can be set to s |
| Internal memory | MicroSD card slot up to 512 GB |
| Pan/Tilt Range | Horizontal: 0°~355°Vertical: -15°~90° |
| Manual speed | Horizontal: 0.1°~36°/s Vertical: 0.1°–25.8°/s |
| Speed between Presets | Horizontal: 35.7°/s Vertical: 27.1°/s |
| Preset positions | 300, 8 tour, 5 Pattern, 5 Scan |
| Communication | ONVIF (profile S, G, T), CGI, SDK, P2P |
| Network interface | Ethernet 10/100 BaseT |
| Remote access | WEB, CMS (DSS/PSS), Smartphone and NVR interface |
| Power | DC 12 V / 1.5 A, max. 15 WPoE (IEEE802.3af) |
| Temp. operation | -30o C ~ +60o C |
| Degree of protection | Weatherproof IP66Surge protection 2000 V |
| Dimensions | 236.2 mm (H) x 140 (W) mm x 142.6 (D) mm |
| Weight | 1.1 Kg |
