| Brand | X-Security |
| Image sensor | 1/2.8" Progressive Scan CMOS |
| Resolution | 4 Megapixel (2560x1440) |
| Lens | Varifocal 2.8~12 mm (optical zoom 4x)) |
| Viewing Angle (FOV) | H: 96.9o~31.6o, V: 51.4o~17.8o, D: 116.2o~36.4o |
| Range performance | 240 m (D), 94.8 m (O), 48 m (R), 24 m (I) |
| Focus | Auto; semi-auto; manual |
| Digital zoom | 16x |
| Electronic Shutter | 1 s~1/30.000 s |
| Minimum illumination | 0.005 Lux @(F1.8, AGC ON)0 lux with IR range 20 m |
| Day / Night | Removable mechanical ICR filter |
| Compression | H.264H; H.264B; Smart H.265+; H.264; H.265; MJPEG (ExtraStream); Smart H.264+ |
| Main Stream rate | 4Mpx/3Mpx/1080p/1.3Mps/720p @(1–25/30 fps) |
| Extra Stream Rate 1 | D1/VGA/CIF@ (1–25/30 fps) |
| Extra Stream Rate 2 | 720p@ (1–25/30 fps) |
| Bitrate | H264: 96 Kbps~14,848 KbpsH265: 38 Kbps~8,960 Kbps |
| Image improvements | WDR (120dB), 2D/ 3DNR, HLC, BLC, ATW, AGC, Smart IR, Rotation 180o |
| EIS (Image Stabilizer) | Yes |
| SMD (Smart Motion Detection) | SMD 3.0, advanced motion detection |
| IVS (Perimeter protection) | Tripwire; intrusion; fence crossing detection; loitering detection; abandoned/lost object; fast movement; parking detection; people gathering; vehicle/human alarm classification |
| Face detection | Supports face detection, image captures, and face enhancement. Supports face trimming: face, one inch photo.Capture strategies include real-time capture and quality prioritization. |
| People count | Supports counting the number of people crossing the detection line, counting the number of people in an area and queue management. In addition, only the count of people crossing the detection line sup |
| Audio | 1 input / 1 outputIntegrated microphone |
| Audio Compression | PCM; G.711A; G.711MU; G.726; MPEG2-Layer2; G.722.1 |
| Internal memory | MicroSD card slot up to 512 GB |
| Pan/Tilt Range | Horizontal: 0°~355°Vertical: 5°~90° |
| Manual speed | Horizontal: 0.1°~70°/s Vertical: 0.1°–30°/s |
| Speed between Presets | Horizontal: 0.1°~80°/s Vertical: 0.1°–40°/s |
| Preset positions | 300, 8 tour |
| Communication | ONVIF (profile S, G, T), CGI, SDK |
| Network interface | Ethernet 10/100 BaseT |
| Remote access | WEB, CMS (DSS/PSS), Smartphone and NVR interface |
| Power | DC 12 V / 2 A, max. 13 WPoE (IEEE802.3af) |
| Temp. operation | -30o C ~ +60o C |
| Degree of protection | Weatherproof IP66Vandal proof IK08Surge protection 6000 V |
| Dimensions | 65.7 mm (H) x 128 (O) mm |
| Weight | 0.5 kg |
