| Brand | X-Security |
| Range | ULTRA |
| Image sensor | PT: 1/2.8“ Progressive Scan CMOSPanoramic: 1/2.8“ Progressive Scan CMOS |
| Resolution | PT: 2 Megapixel (1920x1080)Panoramic: 2 Megapixel (1920x1080) |
| Main Stream rate | PT: 1080p / 720p / 640x360 @(1~25/30 fps)Overview: 1080p / 720p / 640x360 @(1~25/30 fps) |
| Extra Stream Rate 1 | PT: 640x360 / QVGA @(1~25/30 fps)Overview: 640x360 / QVGA @(1~25/30 fps) |
| Minimum illumination | PT: 0.05 Lux @(F1.6, 30 IRE)0 lux with illuminatorIR range: 30 mWhite light range: 30 mPanoramic: 0.05 Lux @(F1.6, 30 IRE)0 lux with illuminatorIR range: 30 mWhite light range: 30 m |
| Compression | H.264H; H.264B; Smart H.265+; H.265; Smart H.264+; H.264M |
| Bitrate | H264: 48 Kbps~4096KbpsH265: 19 Kbps~4096Kbps |
| Lens | PT: 4 mm fixed lensPanoramic: 4 mm fixed lens |
| Viewing Angle (FOV) | PT: H: 85.7o, V: 47.1o, D: 100oOverview: H: 85.7o, V: 47.1o, D: 100o |
| Range performance | 53.6 m (D), 21.2 (O), 10.7 (R), 5.3 (I) |
| Electronic Shutter | PT: 1~1/100.000 sPanoramic: 1~1/100.000 s |
| Day / Night | Removable mechanical ICR filter |
| Image improvements | DWDR, BLC, HLC, 2D/3D-DNR, AGC, AWB, Flip 180o |
| SMD (Smart Motion Detection) | Advanced SMD motion detection 3.0 |
| IVS (Perimeter protection) | Intrusion, tripwire (both functions support the accurate classification and detection of vehicles and persons) |
| Pan/Tilt Range | PT: Horizontal: 0~350°, Vertical: 0°~90° auto flip 180oOverview: Horizontal: 0~290°, Vertical: -10°~15° |
| Manual speed | Horizontal: 0.1~ 36°/s, Vertical: 0.1~25°/s |
| Speed between Presets | Horizontal: 36°/s, Vertical: 25°/s |
| Preset positions | 50 preset |
| Internal memory | MicroSD card slot up to 256 GB |
| Alarms | Built-in alarm and flashing deterrent |
| Audio | Built-in microphone and speaker |
| Audio Compression | PCM; G.711a; G.711Mu; G.726 |
| PTZ Control | Through network access |
| Network interface | Ethernet 10 / 100 BaseT |
| Remote access | WEB, CMS (DMSS/DSS Pro), Smartphone and NVR interface |
| Interoperability | ONVIF (Profiles S, T), CGI, SDK |
| Power | DC 12 V, 1.5 A, max. 12 WPoE (IEEE802.3af) |
| Temp. operation | -20o C ~ +50o C |
| Degree of protection | Weatherproof IP66Surge protection 2000 V |
| Dimensions (without bracket) | 210.1 mm (H) x 159.4 mm (D) x 110 mm (W) |
| Weight (without bracket) | 1 kg |
