| Brand | X-Security |
| Maximum resolution | 4 Megapixel (2688x1520) |
| Image sensor | 1/2.9” Progressive CMOS |
| Lens | 2.8 mm fixed lens |
| Viewing angle | H: 101°; V: 55°; D: 121° |
| Range performance | 63.6 m (D), 25.4 m (O), 12.7 m (R), 6.4 m (I) |
| Main Stream rate | 2688x1520@(1-25/30 fps) |
| Extra Stream rate | 704x576@(1–25 fps) / 704x480@(1–30 fps) |
| Third stream rate | 1920x1080@(1-25/30 fps) |
| Compression | H.265;H.264;H.264H;H.264B;MJPEG |
| Minimum illumination | 0.002 lux@F1.6 (Color, 30 IRE)0.0002 lux@F1.6 (B/W, 30 IRE)0 lux (with IR on) |
| IR range | IR 50m |
| Image improvements | WDR 120 dB, BLC, HLC, AWB, AGC, 3D-NR, ROI , Smart Light, Mirror effect, Privacy masking |
| SMD Plus | Yes (Human and vehicle based motion detection) |
| IVS (Perimeter protection) | Intrusion, tripwire (both functions support the accurate classification and detection of vehicles and persons) |
| AcuPick | Uses deep learning algorithms and works with back-end devices to accurately identify targets, such as people and motor vehicles, and searches live and recorded video to quickly locate targets. |
| Face detection | Face detection; snapshot; snapshot optimization; optimal face snapshot loading; face snapshot enhancement; face exposure; face attribute extraction, including 6 attributes and 8 expressions; setting f |
| People count | Tripwire people counting and area people counting; report generation and export (daily/weekly/monthly/annual); 4 rules can be set for Tripwire, area people counting and queue management. |
| Heat map | Yes |
| Video metadata | Detection of motorized vehicles, non-motorized vehicles, faces and human bodies; snapshot; snapshot optimization; optimal loading of face snapshots. Extraction of attributes of motorized and non-motor |
| Intelligent search | Using microSD card or NVR X-Security |
| Network interface | Ethernet 10/100M BaseT |
| Video output | 1 HDMI port 1.4a |
| Alarms | 1 input / 1 output |
| Audio | 1 input / 1 outputIntegrated microphone |
| Audio Compression | PCM; G.711a; G.711Mu; G.726; G.723 |
| Remote access | WEB, CMS (Smart PSS Lite / DSS / DMSS), Smartphone and NVR interface |
| Material | Metallic |
| Interoperability | ONVIF (Profile S, G, T); CGI |
| Power | DC 12 V / 5.9 W max.PoE IEEE802.3af / 6.9 W max. |
| Temp. operation | -40o C ~ +60o C |
| Degree of protection | Weatherproof IP67Vandal proof IK10 |
| Dimensions | 122 (?) x 94 (H) mm |
| Base dimensions | O base 122 mm / O between bolts 110 mm / 3 bolts |
| Weight | 550 g |
| Colour | Black |
