| Brand | X-Security |
| Maximum resolution | 8 Megapixel (3840 × 2160) |
| Image sensor | 1/2.7” Progressive CMOS |
| Lens | 2.7 mm–13.5 mm (H: 113°–31°; V: 58°–18°; D: 138°–36°) |
| IR range | 40 m |
| Main Stream rate | 3840 × 2160@(1–20 fps)/2688 × 1520@(1–25/30 fps) |
| Extra Stream rate | 704 × 576@(1–25 fps)/704 × 480@(1–30 fps) |
| Compression | H.265; H.264; H.264H; H.264B; MJPEG |
| Smart Codec | Smart H.265+Smart H.264+ |
| Range performance | 85.3-280 (D), 34.1-112 (O), 17.1-56 (R), 8.5-28 (I) |
| Minimum illumination | 0.008 lux@F1.5 (Color, 30 IRE)0.0008 lux@F1.5 (B/W, 30 IRE)0 lux (Illuminator on) |
| Image improvements | WDR 120 dB, BLC, HLC, AWB, AGC, 3D-NR, ROI , Smart IR |
| IVS (Perimeter protection) | Intrusion, tripwire (both functions support the accurate classification and detection of vehicles and persons) |
| Intelligent search | Work together with Smart NVR to refine intelligent search, event extraction and merging with event videos |
| Network interface | Ethernet 10/100 BaseT |
| Audio | Built-in microphone |
| Audio Compression | G.711a; G.711Mu; PCM; G.726 |
| Remote access | WEB, CMS (DSS/PSS), Smartphone and NVR interface |
| Material | Metallic |
| Interoperability | ONVIF (Profile S/Profile T); CGI; P2P; Milestone |
| Power | DC 12 V / 3,4W, PoE IEEE802.3af |
| Temp. operation | -30o C ~ +60o C |
| Degree of protection | Weatherproof IP67, Vandal-proof IK10 |
| Dimensions | 93.4 mm (D) x 122 (O) mm |
| Weight | 500 g |
