| Brand | X-Security |
| Image sensor | 1/2.8” CMOS image sensor |
| Maximum resolution | 2 Megapixel (1920 × 1080) |
| Lens | 2.8 mm (H: 106°; V: 56°; D: 127°) |
| Main Stream rate | 1920 × 1080@(1–25/30 fps) |
| Extra Stream rate | 704 × 576@(1–25 fps)/704 × 480@(1–30 fps) |
| Compression | H.265; H.264; H.264H; H.264B; MJPEG |
| Minimum illumination | 0,002 lux@F1,6 (color, 30 IRE) 0,0002 lux@F1,6 (black and white, 30 IRE) 0 lux (illuminator on) |
| Range performance | 43.9 (D), 17.5 (O), 8.8 (R), 4.4 (I) |
| Video Bit Rate | H.264: 32 kbps–6144 kbpsH.265: 12 kbps–6144 kbps |
| Lens Adjustment | 3 Axis |
| Image improvements | WDR (120 dB), BLC, HLC, AWB, AGC, 3D-NR, ROI , Smart IR |
| IVS (Perimeter protection) | Intrusion, tripwire (both functions support the accurate classification and detection of vehicles and persons) |
| Network interface | Ethernet 10/100 BaseT |
| Audio | Built-in microphone |
| External storage | 256 GB microSD card slot |
| Remote access | WEB, CMS (DSS/PSS), Smartphone and NVR interface |
| Interoperability | ONVIF (Profile S/Profile G); .CGI; P2P |
| Power | DC 12 V / 2.5 W, PoE IEEE802.3af |
| Temp. operation | -40o C ~ +60o C |
| Degree of protection | Waterproof IP67, Anti-vandal IK10 |
| Dimensions | 81 mm (D) x 110 (O) mm |
| Weight | 340 g |
