| Brand | X-Security |
| Image sensor | 1/1.7” Progressive CMOS |
| Maximum resolution | 8 Megapixel (3280x2480) |
| Lens | 1.85mm (Total coverage 360o) (Total coverage [%VAR%]) |
| Display mode | Front end (hardware dewarping): 1O / 1P / 2P / 1R / 2R / 4R / 1O + 3RO: Fisheye viewP: Panoramic viewR: Image region viewRear (Dewarping by softaware)- Fisheye view- Panoramic view 360o + PTZ- Dual ch |
| Video frame | Fisheye mode:1O (3280×2480)1P (4096×1024)2P (2432×2432)1R (1216×1216)2R (2432×2432)4R (2432×2432)1O + 3R (2432×2432) |
| Main Stream rate | 8M (3280x2480@1–25/30 fps) |
| Extra Stream rate | 704×576@1–25/30 fps |
| Third stream rate | 1280x960@1–25/30 fps |
| Compression | H.265+/H.265/H.264+/H.264 |
| Range performance | 40 (D), 16 (O), 8 (R), 4 (I) |
| IVS (Perimeter protection) | Line crossing and intrusion |
| People count | Count of people in area (Entrance / Exit / Inside).Setting up to 4 areasAnnual/monthly/daily and customized reportingAlarm activation in case of exceeding permitted capacity |
| Heat map | Yes |
| Image improvements | DWDR, 3DNR, AWB, AGC, BLC, HLC, Privacy Masking, ROI |
| Audio | 1 Input channel (RCA port)1 Output channel (RCA port)Integrated microphone |
| Network interface | Ethernet 10/100 BaseT |
| Internal memory | MicroSD card up to 256 GB (not included) |
| Alarms | 2 inputs: 5mA 3V–5V DC2 outputs: 300mA 12V DC |
| Remote access | WEB, CMS (DSS/PSS), Smartphone and NVR interface |
| Interoperability | ONVIF |
| Power | DC 12 V / 13W, PoE IEEE802.3af |
| Material | Metallic |
| Degree of protection | Weatherproof IP67, Anti-vandal IK10 |
| Temp. operation | -40o C ~ +60o C |
| Dimensions | 59.8 mm (D) x 149.8 (O) mm |
| Weight | 790 g |
