| Brand | X-Security |
| Image sensor | 1/2.9” CMOS |
| Maximum resolution | 4 Megapixel (2688x1520) |
| Lens | 2.7mm~13.5mm motorized HF |
| Main Stream rate | 2688 × 1520 @ (1–25/30) fps |
| Extra Stream rate | 704 × 576 @ (1–25 fps)/704 × 480 @ (1–30 fps) |
| Compression | H.265; H.264; H.264H; H.264B; MJPEG (only compatible with substream) |
| Infrared lighting | 0,005 lux@F1,5 (color, 30 IRE) 0,0005 lux@F1,5 (black and white, 30 IRE) 0 lux (illuminator on) |
| Range performance | 64-210 (D), 25..6-84 (O), 12.8-42 (R), 6.4-21 (I) |
| Image improvements | WDR, BLC, HLC, AWB, AGC, 3D-DNR, |
| IVS (Perimeter protection) | Tripwire, intrusion (supports accurate classification and detection of vehicles and persons) |
| Quick selection | With AI NVR, quickly collect human/vehicle targets of interest to SMD event users |
| SMD Smart Search | Work together with Smart NVR to refine intelligent search, event extraction and merging with event videos |
| AI SSA | Yes |
| Day / Night | Removable mechanical ICR filter |
| Audio | Built-in microphone |
| Audio Compression | G.711a; G.711Mu; PCM; G.726; G.723 [%VAR%] |
| Network interface | Ethernet 10/100 BaseT |
| Remote access | WEB, CMS (DSS/PSS), Smartphone and NVR interface |
| Interoperability | ONVIF (S Profile /G Profile /T Profile ); .CGI; P2P; Milestone; Genetec |
| Power | DC 12 V / 3,6W, PoE IEEE802.3af |
| Temp. operation | -30o C ~ +60o C |
| Internal memory | Micro SD Max 256GB |
| Degree of protection | Weatherproof IP67 |
| Dimensions | 244.1 mm (D) x 79 (H) mm x 75.9 (W) mm |
| Weight | 820 g |
