| Brand | X-Security |
| Image sensor | 1/2.9” Progressive CMOS |
| Maximum resolution | 4 Megapixel (2688x1520) |
| Lens | 2.8 mm (H: 107°; V: 56°; D: 127°) |
| Main Stream rate | 2688 × 1520 @ (1–25/30) fps |
| Extra Stream rate | 704 × 576 @ (1–25 fps)/704 × 480 @ (1–30 fps) ) |
| IR range | 50 m |
| Compression | H.265; H.264; H.264H; H.264B; MJPEG |
| Infrared lighting | 0,005 lux@F1,4 (color, 30 IRE) 0,0005 lux@F1,4 (black and white, 30 IRE) 0 lux (illuminator on) |
| Image improvements | WDR, BLC, HLC, AWB, AGC, 3D-DNR, SMD |
| IVS (Perimeter protection) | Tripwire, intrusion (supports accurate classification and detection of vehicles and persons) |
| AI SSA (AI Scene Selfadaptation) | Yes |
| Intelligent search | Work together with Smart NVR to refine intelligent search, event extraction and merging with event videos |
| Network interface | Ethernet 10/100 BaseT |
| SMD 4.0 | Yes |
| Audio | 1 IN / 1 OUT / Built-in Microphone |
| Alarms | 1 input channel: 5 mA 3–5 VCC 1 output channel: 300 mA 12 VCC |
| Remote access | WEB, CMS (DSS/PSS), Smartphone and NVR interface |
| Interoperability | ONVIF |
| Power | DC 12 V /4,6 W, PoE IEEE802.3af |
| Temp. operation | -40o C ~ +60o C |
| Internal memory | Micro SD Max 256GB |
| Degree of protection | Weatherproof IP67 |
| Dimensions | 192.7 mm (D) x 70.5 (W) mm x 66.4 (H) mm |
| Weight | 590 g |
