| Brand | X-Security |
| Image sensor | 1/2.9” Progressive CMOS |
| Maximum resolution | 4 Megapixel (2688x1520) |
| Main Stream rate | 2688×1520 (1~20fps), 2560×1440 (1~25/30fps) |
| Extra Stream rate | 2o:704×576 (1~25fps), 704×480 (1~20/30fps) |
| Compression | H.265+/H.265/H.264+/H.264 |
| Lens | 3.6 mm (H: 84°; V: 42°; D: 101°) |
| Minimum illumination | 0.006 Lux@F1.6 |
| Dual Light | IR Range 60m / Warm Light Range 50m |
| Image improvements | WDR, BLC, HLC, AWB, AGC, 3D-DNR, SMD |
| IVS (Perimeter protection) | Intrusion, tripwire (both functions support the accurate classification and detection of vehicles and persons) |
| Day / Night | Removable mechanical ICR filter |
| Network interface | Ethernet 10/100 BaseT |
| Alarms | 1 input / 1 output |
| Audio | 1 Input / 1 Output / Built-in microphone |
| Remote access | WEB, CMS (DSS/PSS), Smartphone and NVR interface |
| Interoperability | ONVIF |
| Power | DC 12 V / 7.2W PoE IEEE802.3af |
| Temp. operation | -40o C ~ +60o C |
| Internal memory | Micro SD Max 256GB |
| Degree of protection | Waterproof IP67, Vandal-resistant IK10 (optional) |
| Dimensions | 238.5× 90.7×90.7 mm |
| Weight | 950 g |
