| Brand | X-Security |
| Image sensor | 1/2.9” Progressive CMOS |
| Maximum resolution | 4 Megapixel (2688 × 1520) |
| Main Stream rate | 2688 × 1520@(1–20 fps)/2560 × 1440@(1–25/30 fps) Sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps) |
| Compression | H.264H; H.265; H.264; H.264B; MJPEG |
| Lens | 2,8 mm: H: 95°; V: 52°; D: 114° |
| Minimum illumination | 0,008 lux@F1,6 (color, 30 IRE) 0,0008 lux@F1,6 (black and white, 30 IRE) 0 lux (illuminator on) |
| Image improvements | WDR, BLC, HLC, AWB, AGC, 3D-DNR, ROI , Smart IR, Mirror |
| IVS (Perimeter protection) | Intrusion, tripwire (both functions support the accurate classification and detection of vehicles and persons) |
| Intelligent search | Work together with Smart NVR to refine intelligent search, event extraction and merging with event videos |
| Day / Night | Removable mechanical ICR filter |
| Network interface | Ethernet 10/100 BaseT |
| Audio | Integrated microphone |
| Remote access | WEB, CMS (DSS/PSS), Smartphone and NVR interface |
| Interoperability | ONVIF |
| Material | Inner core: MetallicCover: Plastic |
| Colour | Black |
| Power | DC 12 V / 5,2W, PoE IEEE802.3af |
| Temp. operation | -30o C ~ +60o C |
| Degree of protection | Weatherproof IP67 |
| Dimensions | 100,9 mm (D) x 109,9 (O) mm |
| Weight | 560 g |
