| Brand | VCA Technology |
| Range | IPAi |
| Model | VCA-IPAi259-FR |
| Image sensor | Sony IMX412 1/2.3” 12.3M CMOS |
| Maximum resolution | 4000(H) x 3000(V) |
| Minimum illumination | Colour: 0.3 Lux B/W : 0 Lux (IR LED On) |
| WDR | True WDR |
| Lens | 1.5mm. |
| Viewing angle | 360° |
| Aperture | F1.8 |
| Shutter | Auto / Manual: 1/30 ~ 1/32000, Anti-Flicker, Slow Shutter (1/2,1/3,1/5,1/6,1/7.5,1/10) |
| IR LED | High Power IR LED x 325m. range |
| Video compression | H.264, H.265, MJPEG |
| Privacy Mask | Up to 16 zones |
| Integrated video analytics | intrusion, detection zones and lines, sabotage detection, appearance, disappearance, permanence, entry, exit, etc |
| Optional video analytics (deep learning) | person tracking, object tracking (person, car, motorcycle), meta data objects |
| Ethernet | 10/100BASE-T |
| ONVIF | ONVIF profile S/T/M |
| Security | HTTPS (SSL), IP filtering, 802.1x, Digest Authentication |
| Protocols | TCP/IP, UDP, AutoIP, RTP (UDP/TCP), RTSP, NTP, HTTP, HTTPS, SSL, DNS, DDNS, DHCP, FTP, SMTP, ICMP, SNMPv1/v2/v3 (MIB 2), UPNP, RTCP, SSH, ONVIF |
| Storage | MicroSD/microSDHC/microSDXC card slot (not included) |
| Audio Compression | G.711 u-law 8KHz, AAC LC 48Kbps at 8KHz |
| Audio input | Microphone included, supply voltage: 2.4VDC (3mA), input impedance: 3K Ohm |
| Audio output | Line output, maximum output level: 1Vrms |
| Construction material | Aluminum (die-casting), black and white |
| Housing | Fisheye |
| Consumption | DC12V max. 10.2WPoE max. 11.5W |
| Power | DC12V, PoE (IEEE 802.3af) PoE (IEEE [%VAR%]) |
| Operating conditions | Humidity 10% ~ 90% RH (non-condensing)-30°C ~ 50°C |
| Standards | FCC, CE, IP67, IK10 |
| Certifications | NDAA compliant |
| Dimensions | O125mm x 58mm |
| Weight | 0.5 kg |
| Warranty | 2 years |
