| Brand | Uni-T |
| Measuring range DC and AC voltage | DC 1000V ±(0.5%+3)AC 750V ±(0.7%+3); Frequency of response: 45~5kHz |
| DC and AC current measuring range | DC 20A ±(0.8%+3)AC 20A ±(1%+3); Frequency of response: 45~5kHz |
| Resistance measuring range | 60M? ±(0.8%+2) |
| Capacitance measuring range | 60mF ±(3%+5) |
| Frequency measurement range | 60Hz~40MHz ±(0.1%+4) |
| Duty Cycle Range | 0.1%~99.9% ±(2%+5) |
| Display accounts | Up to 6000 |
| Auto Range / Manual Range / True RMS | Yes, it has |
| Relative mode | Yes, it is available |
| Continuity test | Yes, it is available |
| Diode test | Yes, it is available |
| Three-phase motor sequence test | Yes, it is available |
| Power | 2 x batteries (LR6) 1.5V |
| Dimensions | 195 (H) x 95 (W) x 58 (D) mm |
| Weight | 484 g |
| Security | CAT III 1000V/ CAT IV 600V CAT IV [%VAR%] |
