TO-TD56304T-RS

TODAIR
Wireless link up to 3 km
Frequency of 5.8 Ghz
Based on 802.11 a/n
IP55, suitable for exterior
RS485 for solar panel and battery monitoring

Brand: MARCA BLANCA

Šifra: TO-TD56304T-RS

GTIN: 8435325492766

81,41 EUR

Dostupno

Dostupnost Dostupno

Načini plaćanja: Pouzećem, online plaćanje po broju narudžbe, PayPal

Specifikacije

Brand	TODAIR
Chipset	Atheros AR9344 600MHz
DRAM	DDR2 64MByte
Flash	8MByte
Ethernet ports	5 ports RJ45 of 10/100 Mbps (if there is an POE48 input on the port ETH1, ports ETH2-3 support a standard 802.3af/at output 48 of [%VAR%] V)
Power connector	1 x DC interface (the ETH2-3 port supports POE48V standard IEEE802.3af/at output when the DC input voltage is 48-52 V)
RS485	Communication port for solar panel and battery monitoring via the manufacturer's cloud platform
Data speed	11a: 54M,48M,36M,24M,18M,12M,9M,6MbpsHT20:7.2M,14.4M,21.7M,28.9M,43.3M,57.8M,65M,72.2M,14.4M,28.9M,43.3M,57.8M,86.7M,115.6M,130M,144.4MbpsHT40:15M,30M,45M,60M,90M,120M,135M,150M,30M,60M,90M,120M,180M,
Transmission	Direct Sequence Spread Spectrum (DSSS)
Modulation	OFDM/BPSK/QPSK/CCK/DQPSK/DBPSK
Network standards	Wireless bridge: IEEE802.11n, IEEE802.11a, IEEE802.3uSwitch: : IEEE802.3, IEEE802.3u, IEEE802.3x, IEEE802.3af, IEEE802.3at
Protocols	CSMA/CA,TCP/IP,IPX/SPX,NetBEUI,DHCP,NDIS3,NDIS4,NDIS5
Supported channels	4900 ~ 6100MHz
Power dissipation	?6W
Power	DC 12-52V / POE 48-56V (PoE 25w per mouth with 60W power)
Performance	Backplane bandwidth 1 GbpsPacket Forwarding Rate: 12,96 MppsEqual speed forwarding to all portsMAC address table size: 4KAutomatic MDI/MDI-X: Yes
RF Power	- 802.11a6-24Mbps 27±2dBm36-48Mbps 26±2dBm54Mbps 25±2dBm- 802.11nHT20MCS 0-3 27±2dBmMCS 4 26±2dBmMCS 5 25.5±2dBmMCS 6 25±2dBmMCS 7 24.5±2dBmHT40MCS 0-3 26±2dBmMCS 4 25.5±2dBmMCS 5 25±2dBmMCS 6 24.5±2d
Sensitivity	802.11a 6Mbps ? -89, 54Mbps ?-73802.11nHT20 MCS 0 ? -86, MCS7?-68 HT40 MCS 0 ? -83, MCS7?-65
Antenna	Frequency range 4900 ~ 6100MhzPolarization - vertical/horizontalGain - 16Dbi
Administration	Web server, SNMP MIB, Telnet, Serial port
Security	MAC control WEP encryption 64/128 bits, WPA, WPA2, 802.1x [%VAR%]
Working temperature	-30 ~ 65?
Storage Temperature	-50 ~ 80?
Relative Humidity	? 95% no condensation
Dimensions	228 x 135 x 43mm
Weight	0.4kg

Opis

The TD-TD56304T-RS is a wireless bridge for communicating distant devices to a 5,8Ghz router or access point outdoors. Achieves wireless speeds up to 300Mbps. It has two RJ45 PoE compatible ports and a RS485 communication bus for battery powered solar panel monitoring. Housing with IP55 wind, rain, dust and sun protection.
