| Mounting | Mast or wall mounting (bolt-on)(Screws not included) |
| LTE Antennas | Frequency Range: 617-960/1700-2700/3300-4300 MHzPolarization: VerticalGain: 4.5dBi (Max)V.S.W.R < 2.5Impedance: 50 ohms2x SMA Male connectors |
| Wi-Fi antennas | Frequency: 2400-2500/4700-6000 MHzPolarization: VerticalGain: 7.5dBiV.S.W.R < 2.0Impedance: 50 ohms2x RP-SMA Male Connectors |
| GNSS Antenna | Frequency: 1560-1610 MHzPolarization: RHCPGain : 28 dBiV.S.W.R < 2.0Impedance: 50 ohmsVoltage 2.5-6.5 VDCCurrent consumption 2.5-6.5 mA1x SMA Male connector |
| Cables | 4x RG3161x RG174 |
| Degree of protection | IP67 |
| Dimensions | 160 x 240 x 189 mm |
| Operating temperature | -40o C ~ +75o C |
| Weight | 1500 g |
| Power | It is necessary to power the indoor Teltonika with Passive PoE, through the LAN1 port with at least the TK-PR324EUB adapter (not included) |
| Compatibility | Compatible with TK-RUT9-Series models |
