| Mounting | Mast or wall mounting (bolt-on)(Screws not included) |
| LTE Antennas | Frequency Range: 617-960, 1700-2700, 3300-4300 MHzPolarization: VerticalGain: 4 dBi (Max)V.S.W.R < 2Impedance: 50 ohms2x SMA Male connectors |
| Wi-Fi antennas | Frequency: 2400-2500/4700-6000 MHzPolarization: VerticalGain: 7,5 dBiV.S.W.R < 2.0Impedance: 50 ohms2x RP-SMA Male Connectors |
| GNSS Antennas | Frequency Range: 1560-1610 MHzPolarization: VerticalGain: 28 dBi (Max)V.S.W.R < 2Impedance: 50 ohms1x SMA Male connectorsConsumption 2.5 - 6.5 mA |
| Bluetooth Antennas | Frequency Range: 2200-27000 MHzPolarization: VerticalGain: 2 dBi (Max)V.S.W.R < 2Impedance: 50 ohms1x RP-SMA Male ConnectorsThe Bluetooth antenna is not used in the router RUTM11 |
| Cables | 5x RG316 1x RG174 |
| Degree of protection | IP67 |
| Dimensions | 160 x 240 x 189 mm |
| Operating temperature | -40o C ~ +75o C |
| Weight | 1500 g |
| Power | It is necessary to power the indoor Teltonika with Passive PoE, through the LAN1 port with at least the TK-PR324EUB adapter (not included) |
| Compatibility | Compatible with TK-RUTX11 and TK-RUTM11 models |
