| Brand | ThermTec |
| Thermal sensor | 384x288 Vanadium Oxide |
| Thermal focus | Motorized |
| Optical sensor | 1/2.8” Progressive Scan CMOS 4 Megapixel |
| Main Stream rate | Term: 768x576 / 640x480 / 384x288 (25fps)Opt: 2592x1536 / 1920x1080 / 1280x720 ?(25fps) |
| Extra Stream rate | Term: 640x480 / 352x288 / 384x288 (25fps)Opt: 1280x720 / 768x576 / 640x480 / 384x288 (25fps) |
| Image Fusion | Supported |
| Compression | H.265 / H.264 |
| Image enhancement | DWDR, 3DNR, BLC, HLC AGC, ROI, Privacy Mask |
| Lens | 35 mm (Therm) / 16 mm (Opt) |
| Thermal viewing angle | 7.5°×5.7° (Therm) |
| Thermal sensitivity | ?35mK (0.05 o C) |
| Thermal measurement range | -20 ~150 o C / ± 8 o C |
| Spectral range | 8~14µm |
| Pitch detector | 12µm |
| Audio | Does not have |
| Alarms | 1 IN / 1 OUT |
| Internal memory | EMMC up to 16GB |
| Network interface | Ethernet 10/100M BaseT |
| Remote access | WEB Interface, Safire Control Center, Safire Connect and NVR |
| Interoperability | ONVIF |
| Power | 12VDC, max.15W / PoE+ (802.3at)1-OUT, up to 15W |
| Temp. operation | -20o C ~ +60o C |
| Degree of protection | Weatherproof IP66 |
| Dimensions | 376 (D) x 142.82 (W) x 102.78 (H) mm |
| Weight | 1800 g |
