| Interfaces | 5 PoE ports RJ45 10/100/1000 Mbps + 1 SFP Gigabit |
| PoE features | Port 1 Hi-PoE up to 60W 802.3btPorts 2-3 PoE+ Up to 30W 802.3af/atPorts 4-5 Passive PoE 24v/48V Up to 25W |
| Controller Batteries | Compatible with 12 V or 24 V 50Ah 5A acid and lithium batteries (battery not included)Compatible with panels up to 400W |
| Loading Functions | Full automatic loadingBattery protectionAutomatic battery voltage recognitionIntegrated lithium battery automatic activation systemPWM charging modeIntegrated low-load start-up protection system |
| Power input | Supports 12V ?33V panel input or 12V batteries (DC 15-26V))Supports 24V ?44V panel input or 24V batteries (DC 26-32V)) |
| Transmission distance | 10BASE-T: Cat3,4,5 UTP (?250 meters)100BASE-TX: Cat5 or later UTP (150 meters) 1000BASE-TX: Cat6 or later UTP (150 meters) 1000BASE-SX: 62.5µm/50µm MMF(2m~550m)1000BASE-LX: 62.5µm/50µm MM(2m~550m) or |
| Bandwidth | 12Gbps |
| Packet forwarding rate | 8,64Mbps |
| MAC Table | 2K |
| Buffer | 2.5MB |
| Power | DC 24V / 2A |
| Dimensions | 160 x 142 x 35 mm |
| Operating temperature | -20o C - 65o C |
| Weight | 720 g |
| Installation | Rack or wall |
| Protections | 3KV 8/20us; IP30 |
