| Brand | Streamax |
| Channels | 4 IP channels |
| Power | 4 PON ports (RJ45) |
| Video compression format | Video: H.265 / H.264Audio: ADPCM,G.711U,G.711A |
| Display resolution | 1080p (1920×1080), 720p (1280×720) |
| Image quality | Levels 1–8 adjustable (preferably Level 1)) |
| Audio | 4 CH |
| Video output | Output: 1 x CVBS + 1xVGA |
| Display divisions | 1 / 4 / 9 |
| Recording method | Home/Manual/Programming/Alarm Event Logging |
| Alarm | Alarm pre-recording: 0-60 minPost-recording:: 0-30 min |
| External Backup | USB memory / HDD USB / CD-RW USB / DVR-RW USB |
| Internal memory | 1 SATA 2.5" HDD or SSD up to 1TB |
| Communication | 3G/4G: EVDO/TD-SCDMA/WCDMA/TDD-LTE/FDD-LTEWIFI: Module W217. Support: 802.11a/b/g/n/acFrequency band: 2.4/5.0 GHz |
| Ports | 1 x SIM Slot1 x RS23232 x RS4851 x CAN1 x speed signal detection channel1 x MIC |
| Alarms | 8 Inputs and 2 Outputs |
| GPS | Positioning, speed detection and time synchronization |
| Power | Input DC 8-36V , Output 5V@500 mA |
| Energy consumption | 35 W |
| Temp. Functioning | 40°C~70°C |
| Dimensions / weight | 70.3 (H) x 190 (W) x 232.9 (D) mm / 1.2 Kg (with hard disk) |
