| Video inputs | 4CH AHD + 1CH IP |
| Input resolution | 4 × 1080p @ 10 FPS (PAL)4 × 720p @ 25 FPS (PAL) |
| Audio | Recording of:4CH AHD + 1CH IP |
| Compression | Video H.264/H.265Audio ADPCM,G.711U,G.711A |
| Recording resolution | AHDMain stream: 1080p (1920 × 1080), 720p (1280 × 720), WD1 (928 × 576), WHD1 (928 × 288), WCIF (464 × 288), D1 (704 × 576), HD1 (704 × 288), CIF (352 × 288);IPC: 1080p (1920 × 1080), 720p (1280 × 720 |
| Summary of Functions | Live viewing, video recording, video playback, network streaming and GPS positioning |
| 4G Communication | LTE FDD: B1/B3/B7/B8/B20/B28ALTE TDD: B38/B40/B41WCDMA: B1/B8GSM: B3/B8 |
| Wi-Fi communication | 2.4 GHz |
| Positioning | GPS |
| Ethernet interface | 1 × 6-pin Aviation connector (100 Mbit/s, Power-PON) |
| Alarms | 8 Inputs / 2 Outputs |
| CAN Bus | Not supported |
| Network Protocols | HTTP, TCP, ARP, UDP, UDP, FTP, DHCP, DNS, IPV4, NTP |
| Storage | 2x SD card slots up to 256GB per slot |
| Management software | Centralized server |
| Temperature range | -40oC to 70oC |
| Power | DC 8-36V, Max. 29WOutput: DC 5V, 500mA |
| Interface | 1x SIM slot, 1x USB-A 2.0, 1xRS232, 1xRS485 |
| Certificates | Emark, CE-RED, FCC-ID, EN50155-EMC, UKCA, EN50155, ROHS, REACH, PTCRB, AT&T, Verizon |
| Dimensions | 167.3 (W) × 146.3 (D) × 54.1 (H) mm |
| Weight | 0.83 Kg |
