| Technology | Double technology: double PIR and microwave with antimasking |
| Detection range | 10 m / H: 7.5o V: 48o / Installation 2.1 m |
| Frequency | 868 MHz Jeweller (Ajax transmitter included) |
| Transmission distance | ? 1200 m in open space |
| Masking | Available |
| Sensitivity | Adjustable for PIR and Microwave. 3 levels |
| Tamper-resistant opening | Available |
| LEDs indication | Alarm |
| DIP Switch configuration | PIR sensitivity, Microwave sensitivity, Antimasking, Battery saving mode and LEDs |
| Wired outputs | Alarm and Tamper |
| Power | 1 battery ER17505 3.6 V |
| Consumption | Minimal consumption (Rest: 50uA / Maximum: 15 mA) |
| Temp. operation | -20 oC ~ 70 oC |
| Degree of protection | IP54 |
| Accessories | L shaped bracket and shield included |
| Dimensions | 140 (H) x 43 (W) x 60 (D) mm |
